Reliable 3300 XL Technology for Industrial Machinery Protection
The 3300 XL 8mm Proximity Probe is designed for applications where accurate shaft displacement measurement and continuous vibration monitoring are essential. Its non-contact design eliminates mechanical wear while providing stable measurement performance during long-term operation.
The 330101 series represents the standard non-armored 8 mm probe configuration with a 3/8-24 UNF thread, offering a practical solution for installations where additional armor protection is not required.
Typical measurement functions include:
-
Radial shaft vibration monitoring
-
Shaft relative displacement measurement
-
Rotor position monitoring
-
Bearing condition analysis
-
Keyphasor® reference measurement
-
Turbine supervisory instrumentation (TSI)
The probe is commonly installed as part of a complete Bently Nevada vibration monitoring system to help operators identify machine condition changes before failures occur.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | Bently Nevada |
| Model Number | 330101-00-32-05-01-05 |
| Product Type | 3300 XL 8mm Proximity Probe |
| Sensor Technology | Eddy Current Non-Contact Sensing |
| Probe Diameter | 8 mm |
| Probe Series | 330101 Standard Mount |
| Thread Type | 3/8-24 UNF |
| Probe Construction | Non-Armored |
| Unthreaded Length Option | 00 |
| Overall Case Length | 3.2 in |
| Total Cable Length | 0.5 m (1.6 ft) |
| Cable Type | Standard Cable |
| Connector Type | Miniature Coaxial ClickLoc Connector with Protector |
| Approval Option | Multiple Approvals |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Compatible Sensor | 3300 XL Proximitor Sensor |
| Operating Temperature | Approx. -51°C to +177°C |
| Probe Dimensions | Approx. 8 mm diameter × 3.2-inch case configuration |
| Probe Weight | Approx. 0.323 kg |
Applications
Built for Critical Rotating Equipment Monitoring
The 330101-00-32-05-01-05 is designed for machinery protection systems where accurate vibration and position feedback are required.
| Industry | Equipment Applications |
|---|
| Power Generation | Steam turbines, gas turbines, generators |
| Oil & Gas | Compressors, pumps, expanders |
| Petrochemical | Centrifugal compressors and process equipment |
| Marine | Turbine-driven machinery |
| Industrial Manufacturing | Motors, gearboxes, rotating assemblies |
Common applications include:
-
Continuous shaft vibration monitoring
-
Rotor displacement measurement
-
Bearing condition monitoring
-
Predictive maintenance programs
-
Machinery protection shutdown systems
-
Online equipment diagnostics
Product Advantages
Accurate Non-Contact Measurement
The eddy current sensing principle allows precise measurement of shaft movement without contact, reducing mechanical wear and improving long-term reliability.
Optimized Standard Mount Design
The standard 330101 configuration provides a compact installation solution for machinery applications that do not require armored probe protection.
Secure ClickLoc Connector System
The ClickLoc connector with protector improves connection reliability and simplifies installation in industrial environments.
Flexible 0.5-Meter Configuration
The short cable configuration is suitable for installations where the probe and monitoring electronics are located close together while maintaining signal integrity.
Proven 3300 XL System Compatibility
The probe integrates with compatible 3300 XL extension cables and Proximitor Sensors, supporting straightforward replacement and system expansion projects.
Technical FAQs
Q1: What is the Bently Nevada 330101-00-32-05-01-05 used for?
It is used for non-contact measurement of shaft vibration, displacement, and position in rotating machinery monitoring systems.
Q2: Which product family does this probe belong to?
It belongs to the Bently Nevada 3300 XL 8mm Proximity Probe Series.
Q3: What sensing technology does it use?
It uses eddy current proximity measurement technology for accurate shaft displacement detection.
Q4: What is the probe diameter?
The probe has an 8 mm sensing tip diameter.
Q5: Is this probe armored?
No. The 330101 series is the standard non-armored probe version.
Q6: What does the "32" option indicate?
The "32" option identifies the 3.2-inch overall case length configuration.
Q7: What does the "05" cable option represent?
The "05" option indicates a 0.5-meter total cable length.
Q8: Which sensor should be paired with this probe?
It should be paired with a compatible 3300 XL Proximitor Sensor and the correct extension cable configuration.
Q9: Can this probe measure both vibration and position?
Yes. The 3300 XL 8mm system supports both dynamic vibration measurement and static shaft position measurement.
Q10: Where is this probe commonly installed?
It is commonly installed on turbines, compressors, generators, pumps, and other critical rotating machinery requiring continuous condition monitoring.
