Product Introduction
Precision Eddy Current Technology for Critical Machinery
The 3300 XL 8mm Proximity Probe is engineered for continuous monitoring of rotating equipment where accurate shaft displacement information is essential. Its non-contact sensing principle eliminates mechanical wear between the probe and rotating shaft, ensuring stable measurement over long operating periods.
This model belongs to the 330101 series, which uses a 3/8-24 UNF threaded probe without armor and is optimized for standard mounting applications.
The probe supports applications such as:
-
Radial shaft vibration measurement
-
Shaft relative displacement monitoring
-
Rotor position measurement
-
Bearing vibration analysis
-
Keyphasor® phase reference applications
-
Turbine supervisory instrumentation (TSI)
The FluidLoc cable option improves resistance against oil and moisture migration through the cable structure, making it suitable for demanding machinery environments.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | Bently Nevada |
| Model Number | 330101-00-18-10-12-00 |
| Product Type | 3300 XL 8mm Proximity Probe |
| Sensor Technology | Eddy Current Non-Contact Measurement |
| Probe Diameter | 8 mm |
| Probe Series | 330101 Standard Probe |
| Mounting Thread | 3/8-24 UNF |
| Armor Type | Without Armor |
| Unthreaded Length Option | 00 |
| Overall Case Length | 18 = 1.8 in |
| Total Cable Length | 10 = 1.0 m (3.3 ft) |
| Cable Type | FluidLoc Cable |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Connector Protector | Not Included |
| Agency Approval | Not Required |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | Stainless Steel |
| Compatible Sensor | 3300 XL Proximitor Sensor |
| Operating Temperature | Approx. -51°C to +177°C |
| Probe Dimensions | Approx. 8 mm diameter × configuration dependent length |
| Typical Weight | Approx. 0.3 kg |
Applications
Reliable Monitoring for High-Performance Rotating Equipment
The 330101-00-18-10-12-00 is designed for machinery protection applications where continuous shaft condition monitoring is required.
| Industry | Typical Equipment |
|---|
| Power Generation | Steam turbines, gas turbines, generators |
| Oil & Gas | Compressors, pumps, expanders |
| Petrochemical | Centrifugal compressors |
| Marine | Turbine-driven equipment |
| Industrial Manufacturing | Motors, gearboxes, rotating machinery |
Typical applications include:
-
Shaft vibration protection
-
Rotor displacement measurement
-
Bearing condition monitoring
-
Machinery diagnostics
-
Predictive maintenance systems
-
Continuous online monitoring
Advantages
Enhanced Fluid Resistance
The FluidLoc cable design helps prevent fluid migration along the cable, improving long-term reliability in oil-rich and industrial environments.
High Measurement Accuracy
The eddy current sensing technology provides precise distance measurement between the probe tip and rotating shaft, supporting accurate vibration analysis.
Non-Contact Operation
Because the probe does not physically contact the rotating component, it reduces mechanical wear and provides consistent performance during continuous operation.
Compact Installation Design
The standard 330101 configuration offers a practical mounting solution for installations where armored protection is unnecessary.
Compatible 3300 XL System Integration
The probe works with compatible 3300 XL extension cables and Proximitor Sensors, allowing easy integration into existing Bently Nevada monitoring systems.
Technical FAQs
Q1: What is the Bently Nevada 330101-00-18-10-12-00 used for?
It is used for non-contact measurement of shaft vibration, displacement, and position in rotating machinery monitoring systems.
Q2: Which series does this probe belong to?
It belongs to the 3300 XL 8mm Proximity Probe Series.
Q3: What is the sensing diameter?
The probe uses an 8 mm sensing tip.
Q4: Does this model include armor protection?
No. The 330101 series is the standard non-armored version.
Q5: What mounting thread does this probe use?
It uses a 3/8-24 UNF thread.
Q6: What does the "18" option represent?
The "18" option identifies the 1.8-inch overall case length configuration.
Q7: What does the "10" option indicate?
The "10" option specifies a 1.0-meter total cable length.
Q8: What is the advantage of FluidLoc cable?
FluidLoc cable technology helps reduce fluid migration through the cable, improving reliability in harsh industrial applications.
Q9: Which Proximitor Sensor should be paired with this probe?
It should be paired with a compatible 3300 XL Proximitor Sensor configured for the matching system length.
Q10: Where is this probe commonly installed?
It is commonly installed on turbines, compressors, pumps, generators, and other critical rotating machinery requiring continuous vibration monitoring.
