External Mounting Housing for 3300 XL 8 mm Proximity Probe Systems

The Bently Nevada 31000-28-10-00-026-00-02 is a 31000 Series Proximity Probe Housing Assembly designed to mount and protect proximity probes installed through rotating machinery casings. It provides external access to the probe and extension cable, allowing technicians to perform probe gap adjustment or probe replacement without dismantling the machine.

The 31000 Series housings are typically used for radial vibration and Keyphasor® measurements and are designed to meet API 670 requirements for externally mounted proximity probe housings.

Product Specifications

Frequently Asked Questions

Does this housing include the proximity probe?

Yes. The 28 option indicates a supplied 3300 XL 8 mm proximity probe with multiple approvals.

What does the “026” option mean?

The 026 option specifies a 2.6-inch probe penetration length, determining how far the probe extends through the machine case.

Are conduit fittings included?

No. The 00 fitting option means the housing is supplied without conduit fittings.

Is this an explosion-proof housing?

No. The 31000 Series provides mechanical and environmental protection. For explosion-proof requirements, Bently Nevada specifies dedicated explosion-proof housing assemblies such as CA21000 or CA24701.
