Bently Nevada 200355-01-00-00 Accelerometers

Name: Bently Nevada 200355-01-00-00 Accelerometers
Brand: Bently Nevada PLC
SKU: 9536
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Bently Nevada PLC
Item No.:200355-01-00-00
Product Origin:USA
Product Dimensions:Ø31.8 × 44.5 mm
Product Weight:0.24kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Product Introduction

The Bently Nevada 200355-01-00-00 Accelerometer is a high-performance piezoelectric vibration sensor engineered for permanent machinery condition monitoring. Designed with a hermetically sealed stainless-steel housing, this accelerometer provides stable acceleration measurements over a wide frequency range while maintaining excellent resistance to harsh environmental conditions. It is compatible with Trendmaster Pro Constant Current Direct Input Cards and Seismic Direct Input Cards, making it an excellent solution for long-term equipment monitoring.

The 200355-01-00-00 configuration features 100 mV/g (±5%) sensitivity, an M6 × 1 mounting stud, and No Agency Approval (00). Compared with the 200350 series, the 200355 offers tighter sensitivity tolerance, lower broadband electrical noise, and an extended low-frequency response for improved measurement performance.

Technical Specifications

Specification	Description
Manufacturer	Bently Nevada
Model Number	200355-01-00-00
Product Type	Accelerometer
Sensor Technology	Piezoelectric
Output Sensitivity	100 mV/g (10.2 mV/m/s²) ±5%
Frequency Response (±3 dB)	0.2 Hz to 10 kHz
Measurement Range	Up to 80 g Peak
Mounted Resonant Frequency	20.8 kHz (Typical)
Broadband Electrical Noise	50 μg (1–10 kHz)
Connector Type	2-Pin MIL-C-5015
Housing Material	Hermetically Sealed Stainless Steel
Mounting Option	01 – M6 × 1 Mounting Stud
Tolerance Option	00
Approval Option	00 – No Agency Approval
Power Requirement	Constant Current Supply
Compatible Hardware	Trendmaster Pro, Seismic Direct Input Cards
Operating Temperature	-54°C to +121°C (-65°F to +250°F)
Shock Limit	5,000 g Peak
Environmental Protection	Hermetically Sealed
Dimensions	Approx. Ø31.8 × 44.5 mm (1.25 × 1.75 in.)
Product Weight	Approx. 0.24 kg
Shipping Weight	Approx. 0.45 kg
Country of Origin	USA

Typical Applications

The 200355-01-00-00 is suitable for continuous vibration monitoring of a wide variety of rotating assets, including:

Steam turbines
Gas turbines
Centrifugal compressors
Pumps
Fans and blowers
Gearboxes
Electric motors
Industrial generators

Its extended low-frequency response makes it particularly effective for detecting a wide range of vibration characteristics in critical machinery.

Product Advantages

Genuine Bently Nevada vibration monitoring sensor.
High-precision 100 mV/g ±5% sensitivity.
Extended frequency response from 0.2 Hz to 10 kHz.
Low broadband electrical noise for improved signal quality.
Hermetically sealed stainless-steel enclosure.
Standard 2-pin MIL connector for reliable connectivity.
M6 × 1 mounting stud configuration.
Suitable for permanent monitoring installations.
Durable construction for demanding operating environments.

Technical FAQs

1. What is the Bently Nevada 200355-01-00-00?
It is a piezoelectric accelerometer designed for continuous machinery vibration monitoring.

2. What sensitivity does this model provide?
The sensor provides 100 mV/g (±5%) output sensitivity.

3. What does mounting option "01" indicate?
Option 01 specifies an M6 × 1 mounting stud.

4. Which connector does the sensor use?
It uses a 2-pin MIL-C-5015 connector.

5. What is the operating temperature range?
The operating temperature range is -54°C to +121°C (-65°F to +250°F).

6. What is the frequency response?
The accelerometer provides a 0.2 Hz to 10 kHz (±3 dB) frequency response.

7. Which monitoring hardware is compatible?
It is compatible with Trendmaster Pro Constant Current Direct Input Cards and Seismic Direct Input Cards.

8. What material is used for the housing?
The housing is manufactured from hermetically sealed stainless steel.

9. What is the approximate product weight?
The accelerometer weighs approximately 0.24 kg, with a typical shipping weight of 0.45 kg.

10. Does this configuration include hazardous-area approvals?
No. Approval option 00 indicates no agency approvals.
