Advanced Single-Axis Motion Control for SLC 500 Automation Systems
The Allen Bradley 1746-HS Motion Control Module is a high-performance single-axis motion control solution developed for the SLC 500 programmable controller platform. Designed to provide accurate servo positioning, speed regulation, and closed-loop motion management, the module delivers reliable control performance for demanding industrial automation applications.
As an IMC 110 motion control system, the 1746-HS integrates directly with motors, encoders, and servo drives to create a responsive and efficient motion platform. Its high-speed processing capability and encoder feedback support make it ideal for applications requiring precise positioning, synchronized motion, and rapid system response.
Widely used in manufacturing, packaging, material handling, and precision machinery, the module combines powerful motion functionality with the proven reliability of the Allen Bradley SLC 500 ecosystem.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Allen Bradley |
| Product Family | SLC 500 |
| Model Number | 1746-HS |
| Module Type | IMC 110 Motion Control Module |
| Motion Axes Supported | Single Axis |
| Control Type | Closed-Loop Servo Positioning |
| Input Voltage | 24V DC |
| Input Frequency | Up to 300 kHz |
| Encoder Feedback | Supported |
| Communication Interface | RS-485 |
| Programming Support | AMP / MML Motion Programming |
| Update Time | Approx. 4.8 ms |
| Input Step Response | Approx. 100 ms |
| Output Step Response | Approx. 2.5 ms |
| Backplane Current | 300 mA @ 5V DC |
| Backplane Current | 104 mA @ 24V DC |
| Installation | Single-slot SLC chassis mounting |
| Compatible Processors | SLC 5/03, 5/04, 5/05 |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | Approx. 145 mm × 35 mm × 152 mm |
| Weight | Approx. 0.14–0.25 kg |
Applications
The 1746-HS module is designed for industrial systems requiring accurate and responsive motion control functionality.
Typical applications include:
-
Servo positioning systems
-
Automated packaging machinery
-
Conveyor synchronization control
-
CNC and precision machine automation
-
Rotary indexing systems
-
Material handling equipment
-
Labeling and printing systems
-
High-speed manufacturing processes
-
Automated assembly systems
Its closed-loop motion capability allows improved positioning accuracy and smoother machine operation compared to conventional mechanical control methods.
Advantages
Precision Closed-Loop Motion Control
Supports encoder feedback for accurate positioning, speed regulation, and repeatable motion performance.
High-Speed Signal Processing
Handles encoder frequencies up to 300 kHz for responsive industrial motion applications.
Powerful Motion Programming Capability
Supports Motion Management Language (MML) and Adjustable Machine Parameters (AMP) programming environments.
Seamless SLC 500 Integration
Works directly within Allen Bradley SLC 500 automation architectures without requiring external controllers.
Efficient Servo System Coordination
Designed for integration with servo drives and encoder-based feedback systems for stable machine control.
Reliable Industrial Performance
Built for continuous operation in demanding manufacturing and industrial environments.
Technical FAQs
1. What is the main function of the 1746-HS module?
It provides single-axis closed-loop motion control for SLC 500 automation systems.
2. What type of motion control does it support?
It supports servo positioning, speed control, and encoder-based motion applications.
3. How many motion axes can it control?
The module supports one motion axis.
4. What is the maximum input frequency?
It supports encoder input frequencies up to 300 kHz.
5. What communication interface does it use?
The module uses an RS-485 communication interface.
6. What programming environments are supported?
It supports Motion Management Language (MML) and Adjustable Machine Parameters (AMP).
7. Which SLC processors are compatible?
It is compatible with SLC 5/03, SLC 5/04, and SLC 5/05 processors.
8. Does it support encoder feedback?
Yes. The module is designed for encoder-based closed-loop motion systems.
9. What industries commonly use the 1746-HS?
Manufacturing, packaging, automation machinery, and material handling industries commonly use this module.
10. Why is the 1746-HS still valuable in industrial systems?
Many facilities continue using proven SLC 500 motion architectures for reliable long-term machine operation and retrofit support.
