The Triconex 9563-810 7760059030 Terminal Board is a compact and reliable interface designed to provide secure connections between field wiring and Triconex control modules. It facilitates organized signal routing and ensures reliable communication within safety and control systems.
From a systems engineering standpoint, this terminal board is ideal for installations requiring neat wiring management, ease of maintenance, and dependable performance in industrial and safety-critical environments.
Technical Specifications
| Parameter | Description |
|---|
| Manufacturer | Triconex |
| Model | 9563-810 |
| Part Number | 7760059030 |
| Product Type | Terminal Board |
| Primary Function | Termination and routing of field wiring to control modules |
| Mounting | Panel or enclosure mounting |
| Features | Organized terminal connections, compact design |
| Dimensions | 114.3 × 127 × 107.95 mm (H x W x D) |
| Weight | Approx. 0.38 kg |
Technical FAQs
1. What is the primary function of the 9563-810 terminal board?
It serves as a structured termination point for field wiring to Triconex control modules.
2. Where is this terminal board installed?
It is typically mounted inside control panels or enclosures.
3. Can it handle multiple field device connections?
Yes, it provides organized terminals for connecting multiple input and output signals.
4. Is it suitable for safety-critical systems?
Yes, it is designed to maintain reliable wiring in safety and control applications.
5. How does it aid maintenance and troubleshooting?
By providing structured wiring, it allows easy access for inspection, testing, and replacement.
6. Can it be used in compact or tight installations?
Yes, its compact form factor makes it ideal for space-constrained environments.
7. Is it compatible with all Triconex modules?
It is fully compatible with standard Triconex controllers and I/O modules.
8. Does installation require special tools?
No, standard wiring practices and tools for terminal connections are sufficient.
9. Can it operate reliably in industrial environments?
Yes, it is built to withstand harsh industrial conditions.
10. Why choose the 9563-810 terminal board over generic terminal boards?
It provides structured, reliable, and system-compatible connections within Triconex safety and control architectures.
