Industrial-Grade Safety Input Control with EtherNet/IP Connectivity
The Allen Bradley 1791ES-IB16 EtherNet/IP Safety CompactBlock Input Module is designed to provide high-performance distributed safety input monitoring for advanced industrial automation systems. Combining integrated safety functionality with EtherNet/IP communication, this module helps manufacturers simplify machine safety architectures while maintaining reliable operational control across demanding production environments.
Its compact all-in-one structure reduces installation complexity and supports efficient machine-level integration. Built for modern industrial applications requiring dependable safety performance, the 1791ES-IB16 offers stable communication, streamlined wiring, and long-term operational reliability for critical automation processes.
Technical Specifications & Mechanical Details
| Specification | Details |
|---|
| Product Series | EtherNet/IP Safety CompactBlock |
| Module Type | Safety Input Module |
| Manufacturer | Allen Bradley |
| Model Number | 1791ES-IB16 |
| Communication Protocol | EtherNet/IP |
| Input Channels | 16 Safety Inputs |
| Input Signal Type | 24V DC Digital Inputs |
| Network Interface | Integrated EtherNet/IP Port |
| Mounting Options | DIN Rail / Panel Mount |
| Housing Material | Industrial Thermoplastic |
| Protection Rating | IP20 |
| Operating Temperature Range | 0°C to 55°C |
| Storage Temperature Range | -25°C to 75°C |
| Electrical Isolation | Industrial Isolation Protection |
| Environmental Design | Heavy-Duty Industrial Use |
| Dimensions | Approx. 235 x 105 x 62 mm |
| Weight | Approx. 1.15 kg |
