ABB TU830V1 3BSE013234R2 S800 I/O System Extended Module Termination Unit

Brand:ABB PLC
Item No.:TU830V1 3BSE013234R2
Product Origin:Sweden (SE)
Product Dimensions:120.5 × 110 × 64 mm
Product Weight:0.25kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

TU830V1 3BSE013234R2 4TU830V1 3BSE013234R2 5TU830V1 3BSE013234R2 2TU830V1 3BSE013234R2 3TU830V1 3BSE013234R2

Advanced Extended MTU for High-Density ABB S800 I/O Architectures

The ABB TU830V1 (3BSE013234R2) Extended Module Termination Unit is a high-performance passive interface module developed for ABB S800 I/O systems and ABB 800xA distributed control platforms. Designed for complex industrial automation environments, it provides reliable field wiring termination, structured signal distribution, and stable ModuleBus communication between connected I/O modules.

As an extended MTU solution, the TU830V1 R2 version supports high-density channel integration and optimized cabinet organization, making it ideal for large-scale process control systems where operational reliability and installation efficiency are critical. Its industrial-grade design ensures long-term performance in demanding process industries.

Technical Specifications

Specification ItemDetails
ModelTU830V1
Revision Number3BSE013234R2
ManufacturerABB
Product TypeExtended Module Termination Unit (MTU)
System CompatibilityABB S800 I/O / 800xA
Channel CapacityUp to 16 channels
Terminal Configuration2 × 16 terminal structure
Rated Voltage50 V
Maximum Current per Channelup to 2 A
Process Voltage Groups2 isolated groups
Fuse Protection6.3 A integrated fuse per group
FunctionField wiring termination + ModuleBus distribution
Mounting TypeDIN rail installation
Mechanical KeyingSupported
Protection RatingIP20
Operating Temperature0°C to +55°C
Approximate Dimensions120.5 × 110 × 64 mm
Approximate Weight~0.25 kg


Industrial Application Areas

The TU830V1 R2 is widely used in industrial control systems where high-density field wiring and stable communication infrastructure are essential. It supports organized I/O system expansion while improving maintainability and signal reliability.

Typical application environments include:

  • ABB 800xA distributed control systems
  • S800 I/O process automation cabinets
  • Oil and gas processing facilities
  • Petrochemical and refinery systems
  • Power generation plants
  • Water treatment automation systems
  • Industrial manufacturing process control
  • Utility and infrastructure monitoring systems

Its extended termination architecture allows engineers to simplify large-scale cabinet wiring while maintaining strong operational stability.


Key Features and Operational Advantages

Extended High-Density Channel Design

Supports up to 16 channels in a structured layout, enabling efficient integration of large-scale field wiring systems.

Reliable Signal Termination

Provides stable field wiring connections that help reduce signal interference and improve system consistency.

Integrated ModuleBus Distribution

Ensures reliable communication routing between connected S800 I/O modules within ABB automation systems.

Dual Isolated Voltage Groups

Two separated process voltage groups improve electrical segmentation and system safety.

Mechanical Keying Protection

Prevents incorrect module insertion, helping reduce maintenance errors and improve operational reliability.

Compact DIN Rail Integration

Optimized for high-density control cabinets where space efficiency and organized wiring are important.


Technical FAQs

1. What is the main purpose of the TU830V1 R2 module?

It provides field wiring termination and ModuleBus distribution for ABB S800 I/O systems.

2. Is this module active or passive?

It is a passive termination unit without signal processing functionality.

3. How many channels are supported?

The module supports up to 16 channels.

4. What systems is TU830V1 R2 compatible with?

It is designed for ABB S800 I/O and ABB 800xA control systems.

5. Does the module support process voltage grouping?

Yes, it includes two isolated process voltage groups.

6. What is the purpose of ModuleBus?

ModuleBus enables internal communication between connected I/O modules.

7. How is the module installed?

It is mounted on a standard DIN rail within industrial control cabinets.

8. Does it include protection features?

Yes, integrated fuse protection supports stable and secure operation.

9. Which industries commonly use this MTU?

Oil and gas, power generation, chemical processing, water treatment, and manufacturing industries.

10. Why is TU830V1 R2 suitable for large automation systems?

Its high-density architecture, stable communication support, and structured wiring design make it ideal for scalable industrial applications.
