Emerson KC3010X1-BA1 Analog Input Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Emerson KC3010X1-BA1 Analog Input Module

Name: Emerson KC3010X1-BA1 Analog Input Module
Brand: Emerson Module
SKU: 7145
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Emerson Module
Item No.:KC3010X1-BA1
Product Origin:USA
Product Dimensions:104 × 318 × 264 mm
Product Weight:0.18kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Emerson KC3010X1‑BA1 analog input module is a high‑precision I/O component engineered for Emerson’s DeltaV™ distributed control system (DCS). Built to handle analog signals from field devices such as transmitters and sensors, this module delivers accurate process measurements for critical automation control loops. Its 16‑channel architecture, HART support, and rugged industrial design make it a versatile choice for process plants, utilities, and large‑scale automation projects where reliability and data integrity are paramount.

Technical Specifications

Parameter	Details
Manufacturer	Emerson
Model Number	KC3010X1‑BA1
Module Type	Analog Input Module
System	DeltaV™ Distributed Control System
Input Channels	16 channels
Input Signal Range	4–20 mA (HART compatible)
Analog Accuracy	±0.15 % of full scale (typ.)
Resolution	0.01 % of full scale
Update Rate	~250 ms per channel
Local Bus Power	12 VDC @ 150 mA
Field Bus Power	24 VDC @ 500 mA
Field Circuit Power	24 VDC @ 30 mA per channel
Operating Temperature	‑40 °C to +70 °C
Storage Temperature	‑40 °C to +85 °C
Humidity	5 %–95 % non‑condensing
Vibration	1 mm peak‑to‑peak (2–13.2 Hz); 0.7 g (13.2–150 Hz)
Shock	10 g half‑sine, 11 ms
Airborne Contaminants	ISA‑S71.04 Class G3
Dimensions (Approx.)	104 × 318 × 264 mm
Weight	~0.18 kg

Applications

The KC3010X1‑BA1 excels in environments where reliable acquisition of analog process data is essential:

4–20 mA sensor signal capture in refinery and chemical processes
Level, flow, pressure, and temperature transmitter interfacing
Distributed DeltaV process control loops
Water and wastewater monitoring systems
Hazardous area analog data acquisition

Its HART compatibility supports smart transmitter communication for enhanced diagnostics and field device management.

Advantages

Engineers choose the KC3010X1‑BA1 for its balance of precision, durability, and integration capabilities:

High Channel Density: 16 analog channels reduce rack footprint and wiring complexity.
Accurate Analog Handling: Tight accuracy and high resolution support precise PID control and process analytics.
HART Enabled: Integrates with smart transmitters for enhanced diagnostics and field device data.
Robust Environmental Ratings: Wide temperature, vibration, and shock tolerance for industrial conditions.
Field‑Ready Power: Dual bus and field power provisions support efficient installation and operation.

These strengths make it especially reliable for continuous process monitoring and control in mission‑critical automation systems.

Technical FAQs

1. How many analog channels does the KC3010X1‑BA1 support?
It supports 16 analog input channels.

2. What signal types can it read?
Designed for standard 4–20 mA signals and HART‑capable transmitters.

3. Does it support smart transmitter diagnostics?
Yes, the module supports HART communication for device diagnostics.

4. What power does the module require?
Local bus power is 12 VDC @ 150 mA; field bus power is 24 VDC @ 500 mA.

5. What is the analog accuracy?
Typical accuracy is ±0.15 % of full‑scale.

6. What is the operating temperature range?
It operates from ‑40 °C up to +70 °C.

7. Can it handle vibration and shock?
Yes, it is rated for industrial vibration and 10 g shock conditions.

8. Is calibration required?
Calibration is generally not required for normal operation.

9. How fast are input updates?
Typical update rate is around 250 ms per channel.

10. Can this module be used in hazardous areas?
Yes, it often carries ATEX/IECEx and FM certifications for hazardous locations, depending on regional requirements.
