Product Overview
The ABB GD C806 A1002 3BHE028761R1002 PCB Card is a compact and reliable circuit board designed for use in ABB industrial automation and drive systems. It serves as a key internal component, enabling signal processing and communication between system modules.
Its lightweight construction and compact size make it ideal for installation in tightly integrated control assemblies. Designed with durability in mind, it performs reliably under industrial conditions, making it well-suited for both new installations and maintenance replacements.
For field engineers and maintenance teams, the GD C806 A1002 provides a dependable solution for maintaining system functionality, minimizing downtime, and ensuring continued operational efficiency.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | ABB |
| Model Number | 3BHE028761R1002 |
| Module Type | PCB Card |
| Function | Internal Signal Processing and Circuit Interface |
| System Compatibility | ABB Automation and Drive Systems |
| Installation | Internal Rack / Control Unit Mount |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | 120 mm × 100 mm × 25 mm |
| Weight | 0.25 kg (0.55 lb) |
Applications in Control and Monitoring Circuits
The ABB GD C806 A1002 PCB Card is designed as a core electronic component within ABB automation and drive systems, supporting signal processing and internal communication between control elements. It plays a crucial role in maintaining stable system behavior, particularly in environments where precise control and monitoring are required.
Typical application areas include:
-
Industrial Drive Systems: Supports internal signal processing within drive control architectures.
-
Automation Control Panels: Provides circuit-level connectivity between controllers and I/O interfaces.
-
Process Industries: Ensures reliable operation in chemical, oil & gas, and power generation environments.
-
Manufacturing Equipment: Enables consistent communication between machine control subsystems.
-
Maintenance and Replacement Projects: Commonly used as a service replacement board in ABB systems.
Its role is especially important in maintaining continuous operation and minimizing system downtime during maintenance cycles.
Advantages for Maintenance and Operation
-
Reliable Circuit-Level Performance: Ensures stable signal transmission and processing within control systems.
-
Compact Form Factor: Dimensions of 120 mm × 100 mm × 25 mm allow easy integration into dense assemblies.
-
Lightweight for Quick Replacement: Weighs 0.25 kg (0.55 lb), making handling and installation straightforward during service tasks.
-
Designed for ABB System Compatibility: Integrates seamlessly into ABB automation and drive platforms.
-
Robust Industrial Design: Withstands electrical noise, vibration, and operational stress typical in industrial environments.
