Technical FAQs

1. What type of outputs does this module provide?
   It provides 32 high‑side current sourcing digital outputs.
2. What voltage range does it operate under?
   It supports 10.5 – 32 V DC input.
3. Can it drive high‑current loads?
   Individual outputs support up to 0.5 A, with group limits of 6 A and module limits of 12 A.
4. Is the module isolated?
   Yes — outputs are divided into two galvanically isolated groups of 16.
5. Does it protect against overloads?
   Yes, active current limiting is integrated per group.
6. How quickly do outputs switch?
   Typical OFF‑to‑ON and ON‑to‑OFF response times are around 6 ms.
7. What kind of protection is built in?
   Electronic limiting protects against overcurrent and short conditions.
8. Does it support incandescent lamp loads?
   Yes, with reduced per‑point current limits (~0.25 A).
9. Can the module be reset without power cycling?
   Yes — fault groups reset automatically without full power cycling.
10. Can it be used outside HC900 systems?
    It’s optimized for Honeywell ControlEdge HC900 I/O architecture but may integrate into compatible environments.
