Yokogawa ATR8S-10 Pressure Clamp Terminal Block

Brand:Yokogawa Electric
Item No.:ATR8S-10
Product Origin:Japan
Product Dimensions:114 x 32.6 x 60.5 mm
Product Weight:0.2 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

ATR8S-10-1ATR8S-10-3ATR8S-10-2ATR8S-10-4

Industrial‑Grade Pressure Clamp Terminal Block for Signal Wiring

The Yokogawa ATR8S‑10 Pressure Clamp Terminal Block is a high‑reliability wiring interface designed to facilitate field signal termination in complex industrial control systems — particularly Yokogawa’s CENTUM VP and similar distributed control/DCS platforms. This model extends the basic ATR8S‑00 by incorporating enhanced features such as surge‑absorption support, making it especially suitable where analog RTD sensor wiring must be protected against transient electrical disturbances. Its modular design and rugged construction ensure long‑term stability and signal integrity in demanding automation environments.

Technical Specifications

SpecificationDetails
ManufacturerYokogawa Electric Corporation
ModelATR8S‑10 Pressure Clamp Terminal Block
Product TypePressure Clamp Terminal Block
ApplicationField wiring termination for RTD/analog signals
Connection TypePressure clamp with surge absorber option
Compatible ModulesRTD/analog input modules (e.g., AAR181 with R8S10)
Rated VoltageStandard control system voltages (industrial use)
Rated CurrentTypical low‑power field I/O signal circuits
MountingDIN‑rail or panel mount
MaterialIndustrial‑grade insulating and conductive materials
Connection DensityHigh channel count (for compact panel layouts)
WeightIndustrial terminal block weight (modular design)
Operating EnvironmentIndustrial control cabinets and enclosures
WarrantyStandard 12‑month supplier warranty
OriginJapan


Typical Industrial Applications

The ATR8S‑10 is engineered for environments where secure signal termination is critical:

  • Field signal wiring for Resistance Temperature Detectors (RTDs) and analog sensors.
  • Cabinet wiring in process automation facilities (petrochemical, water treatment, power generation).
  • Distribution panels where structured termination enhances maintenance and traceability.
  • Control racks requiring stable, low‑noise connections for critical process data.
  • Upgrades and maintenance of Yokogawa distributed I/O systems without system architecture changes.

By standardizing termination practices and extending surge protection at the connection point, the ATR8S‑10 helps maintain consistent signal quality and reduce wiring errors in large automation networks.


Core Advantages

  • Pressure Clamp Reliability: Ensures stable, vibration‑resistant electrical connections that maintain signal integrity in industrial conditions.
  • Surge Absorber Support: The “‑10” variant is designed to integrate surge protection at field termination for improved transient robustness.
  • Modular Rack Integration: Fits DIN rails or panel slots with ease, simplifying cabinet layout and field wiring.
  • Industry Proven: Developed for Yokogawa DCS control architectures, ensuring compatibility and long‑term support.
  • Compact and Organized: High‑density layout reduces clutter and helps maintain orderly signal wiring documentation.


Technical FAQs

1. What is the main purpose of the ATR8S‑10?
It provides a secure and organized way to terminate field sensor wiring, especially resistance thermometer (RTD) and analog signals, to the control system’s I/O modules.

2. How does it differ from the ATR8S‑00?
The ATR8S‑10 includes provisions for surge absorption at the terminal block, improving protection against transient electrical disturbances.

3. What types of signals can it handle?
Primarily RTD and other low‑power analog field signals used in process monitoring.

4. Is it compatible with Yokogawa DCS systems?
Yes — it is specifically designed for use with Yokogawa analog/RTD input modules in CENTUM VP and similar environments.

5. Does it require external power?
No — terminal blocks are passive devices and do not require external power.

6. What is the typical mounting method?
The unit installs on DIN rails or panel shelves within control cabinets.

7. Does it improve signal quality?
By providing secure connections and support for surge protection, it helps maintain consistent signal transmission.

8. Is this a high‑density block?
Yes — it supports a dense array of connections suitable for compact cabinet layouts.

9. Can it handle field vibration?
Yes — pressure clamp design resists loosening under vibration.

10. What warranty does it typically carry?
Standard 12‑month supplier warranty on new, genuine parts.
