Yokogawa F3WD64-3P Input/Output Modules

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Yokogawa F3WD64-3P Input/Output Modules

Name: Yokogawa F3WD64-3P Input/Output Modules
Brand: Yokogawa Electric
SKU: 8069
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.:F3WD64-3P
Product Origin:Japan
Product Dimensions:28.9 × 100 × 83.2 mm
Product Weight:0.1 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Product Insight and Functional Overview

The Yokogawa F3WD64-3P Input/Output Module is a compact yet powerful digital I/O solution designed for the FA-M3 PLC platform. Engineered for reliability and high-speed signal processing, it integrates both input and output capabilities into a single module, reducing hardware footprint while maximizing system efficiency. With built-in protection features and flexible configuration, it is well-suited for demanding industrial automation environments where precision and uptime are critical.

Technical Specifications

Parameter	Details
Manufacturer	Yokogawa
Model	F3WD64-3P
Module Type	Input/Output Module
Input Channels	32 (DC Voltage)
Output Channels	32 (Transistor, Sink Type)
Input Voltage	24 V DC (20.4–26.4 V DC)
Output Voltage	24 V DC
Input Current	4.1 mA per point
Output Current	0.1 A per point, 0.4 A per common
Isolation	Photocoupler (1500 V AC, 1 min)
Response Time	≤ 1 ms
Input Sampling Options	0 μs / 62.5 μs / 250 μs / 1 ms
Protection Features	Short-circuit, overheat, surge protection
External Power Supply	24 V DC, 55 mA
Backplane Consumption	170 mA @ 5 V DC
Connection Type	40-pin connectors × 2
Operating Temperature	0°C to 55°C

Typical Industry Applications

The F3WD64-3P is widely implemented in automation systems that require efficient digital signal handling. It is commonly used in manufacturing lines, packaging equipment, semiconductor machinery, and process control systems. Its ability to manage both input monitoring and output control within one module makes it ideal for compact control cabinets and high-density I/O environments.

Core Strengths and Benefits

One of the key advantages of this module is its integrated design, which reduces wiring complexity and saves installation space. The inclusion of short-circuit and thermal protection enhances system safety and minimizes downtime risks. Its configurable input sampling allows engineers to fine-tune performance based on application needs, while the robust isolation ensures stable operation in electrically noisy environments.

The module also supports consistent performance under continuous industrial workloads, making it a dependable choice for long-term deployment in automation systems.

Technical FAQs

What type of signals does the module support?
It supports DC digital input and transistor sink output signals.

How many I/O points are available?
A total of 64 points: 32 inputs and 32 outputs.

Is electrical isolation included?
Yes, photocoupler isolation is provided for all channels.

Can the module handle short circuits?
Yes, it includes built-in short-circuit and overheat protection.

What is the response speed?
The output response time is within 1 ms.

Is input filtering adjustable?
Yes, input sampling time can be configured in multiple steps.

What type of output is used?
Transistor output (sink type).

How is the module connected?
Through dual 40-pin connectors.

What environments is it suitable for?
Industrial environments with moderate temperature and humidity ranges.

Does it support high-density installations?
Yes, its compact design is ideal for space-constrained systems.
