Honeywell 8C‑PAZH52 Digital Output Module

Name: Honeywell 8C‑PAZH52 Digital Output Module
Brand: Honeywell DCS
SKU: 197
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Honeywell DCS
Item No.:8C-PAZH52
Product Origin:USA
Product Dimensions:140 × 100 × 60 mm
Product Weight:0.4 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Honeywell 8C‑PAZH52 is a digital output module designed for industrial automation and process control systems. It provides reliable switching to control external devices such as actuators, valves, alarms, and indicators. Engineered for durability and precise operation, this module integrates seamlessly into Honeywell control racks, offering compact design, electrical isolation, and robust performance for both new installations and legacy system retrofits.

Technical Specifications

Parameter	Specification
Module Type	Digital Output Module
Model	8C‑PAZH52
Output Type	Digital relay or contact output
Supply Voltage	24 V DC
Maximum Output Load	5 A per channel
Communication Interface	Modbus RTU (for networked I/O configurations)
Isolation	Electrically isolated outputs for safety and noise immunity
Operating Temperature	–20 °C to +60 °C
Storage Temperature	–40 °C to +70 °C
Humidity	5–90% RH, non-condensing
Mounting	Rack or panel mount compatible with Honeywell control systems
Dimensions	140 × 100 × 60 mm (H × W × D)
Weight	0.4 kg

Applications

Driving external actuators, valves, alarms, or indicator devices
Expanding digital output capacity in Honeywell 8C-series PLC or I/O racks
Retrofitting control panels with additional output capability
Distributed control systems requiring networked digital outputs
Industrial environments where compact and reliable discrete output is required

Advantages

Compact footprint for space-efficient installation
Reliable output control for industrial devices up to 5 A
Electrical isolation ensures signal integrity and operator safety
Flexible integration with Modbus RTU for networked I/O applications
Wide operating temperature range suitable for harsh industrial environments
Lightweight and easy to install, simplifying replacement and upgrades

Technical FAQs

What is the primary function of the 8C‑PAZH52?
It serves as a digital output module for controlling external devices in automation systems.
What supply voltage does it require?
24 V DC.
What is the maximum output load?
Up to 5 A per channel.
Are the outputs electrically isolated?
Yes, outputs are isolated to protect the system and reduce interference.
Which communication protocol does it support?
Modbus RTU for networked I/O configurations.
What is the operating temperature range?
–20 °C to +60 °C.
What are the module dimensions and weight?
140 × 100 × 60 mm (H × W × D), weight 0.4 kg.
Can it be mounted in standard Honeywell racks?
Yes, compatible with rack and panel mounting in Honeywell control systems.
Is it suitable for retrofitting legacy systems?
Yes, it can expand output capabilities without major system redesign.
What types of devices can it drive?
Actuators, valves, alarms, indicators, or other devices requiring a 24 V DC digital output.
