Technical FAQs

1. What is the Bently Nevada 990-05-70-01-IN used for?

It is used for continuous vibration monitoring of rotating machinery by converting proximity probe vibration signals into a 4–20 mA control signal.

2. What type of sensor does this transmitter support?

The transmitter is designed for use with a 3300 NSv proximity probe and matching extension cable system.

3. What does the “05” in the model number mean?

The “05” indicates a full-scale vibration measurement range of 0–5 mils peak-to-peak (0–125 μm pp).

4. What does the “70” option represent?

The “70” identifies the 7.0-meter (23 ft) transducer system length configuration.

5. What mounting method does this model use?

The “01” option specifies 35 mm DIN rail mounting clips for panel installation.

6. What output signal does the transmitter provide?

It provides a proportional 4–20 mA analog vibration output for connection to industrial control systems.

7. Does the transmitter require an external Proximitor module?

No. The unit includes integrated Proximitor® electronics, reducing additional hardware requirements.

8. Can this transmitter be connected directly to a PLC or DCS?

Yes. The standard 4–20 mA output allows direct integration with most industrial automation systems.

9. What diagnostic features are available?

The transmitter provides PROX OUT and gap voltage monitoring functions for system testing and maintenance.

10. What equipment commonly uses this transmitter?

It is commonly installed on compressors, pumps, motors, fans, blowers, and other rotating machinery requiring continuous vibration monitoring.
