Applications
The BMXERT1604T is tailored for control systems where mixed signal acquisition and additional timing/counting features improve efficiency and reduce system complexity:
-
Process Monitoring and Control – Simultaneous capture of discrete status and analog process variables
-
Machine Automation – Monitoring inputs from switches, sensors, and transducers in automated equipment
-
Energy and Utility Systems – Analog measurement of process values such as flow, pressure, and level
-
Manufacturing Lines – Fast digital input scanning combined with analog feedback for quality control loops
-
Material Handling – Input capture for sensors, counters, and timing logic in conveyor systems
By combining multiple input types in one module, system architecture is simplified and installation costs are reduced.
Applications
The BMXERT1604T is tailored for control systems where mixed signal acquisition and additional timing/counting features improve efficiency and reduce system complexity:
-
Process Monitoring and Control – Simultaneous capture of discrete status and analog process variables
-
Machine Automation – Monitoring inputs from switches, sensors, and transducers in automated equipment
-
Energy and Utility Systems – Analog measurement of process values such as flow, pressure, and level
-
Manufacturing Lines – Fast digital input scanning combined with analog feedback for quality control loops
-
Material Handling – Input capture for sensors, counters, and timing logic in conveyor systems
By combining multiple input types in one module, system architecture is simplified and installation costs are reduced.
Technical FAQs
-
What types of inputs does the BMXERT1604T support?
It supports 16 digital discrete inputs and 4 multifunction analog inputs configurable for voltage or current.
-
What analog signal ranges are supported?
Voltage ranges such as ±10 V, 0–10 V, 0–5 V and current range 4–20 mA are supported.
-
Can this module perform counting or timing functions?
Yes, selected input channels offer high‑speed counting and timing capabilities.
-
Is the module isolated from the PLC logic?
Yes, groups of inputs are optically isolated for noise immunity and reliability.
-
Are there visual status indicators?
Yes, each input, along with module status, has LED indicators for quick diagnostics.
-
What mounting options does it support?
Designed for DIN rail or backplane installation in Modicon X80 systems.
-
What is the operating temperature range?
Standard operation is between 0 °C and +60 °C.
-
What protection rating does it have?
IP20, suitable for industrial control environments.
-
Can this module be expanded in larger systems?
Yes, it integrates seamlessly with other Modicon X80 I/O modules for scalable automation systems.
-
Is this module suitable for noisy industrial environments?
The optical isolation and industrial design support reliable use in such environments.
