GE IC697MDL710 Relay Output Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

GE IC697MDL710 Relay Output Module

Name: GE IC697MDL710 Relay Output Module
Brand: GE Fanuc PLC
SKU: 7948
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:GE Fanuc PLC
Item No.:IC697MDL710
Product Origin:USA
Product Dimensions:200 × 40 × 150 mm
Product Weight:0.55kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction — Reliable Relay-Based Output Switching for Industrial Control Systems

The GE IC697MDL710 Relay Output Module is a discrete relay output module designed for GE Fanuc Series 90-70 PLC systems. It is built to provide electrically isolated switching of field devices such as solenoids, contactors, relays, alarms, and indicator loads.

Unlike transistor or triac output modules, this relay-based design offers true mechanical isolation, making it suitable for mixed-voltage environments and applications requiring robust load compatibility and signal separation.

Technical Specifications — Electrical & Functional Overview

Specification	Details
Module Type	Relay Output Module
Model / Part Number	IC697MDL710
PLC Series Compatibility	GE Fanuc Series 90-70
Output Type	Relay (dry contact switching)
Output Points	16 points (typical configuration)
Output Isolation	Channel-level relay isolation
Load Compatibility	AC and DC mixed loads
Switching Capacity	Medium power industrial loads
Contact Type	Form A / Form C (relay-based configuration)
Response Type	Mechanical switching
LED Indicators	Yes (per-channel status indication)
Backplane Power	5 V DC
Configuration Method	Software-based (no hardware jumpers)
Installation Type	Rack-mounted (Series 90-70 slot)
Operating Temperature	Industrial-grade range
Weight	Approx. 0.5–1.5 kg

Applications — Flexible Load Switching in Industrial Environments

The IC697MDL710 module is widely used in automation systems requiring reliable relay-based output control:

GE Series 90-70 PLC control systems
Oil & gas processing and pipeline control systems
Petrochemical and refinery automation
Power generation auxiliary control systems
Industrial machine control panels
Conveyor and material handling systems
Alarm, indicator, and safety interlock circuits

Advantages — Electrical Isolation and Load Flexibility

True Relay Output Design ensures complete electrical isolation
Supports AC and DC Loads for flexible industrial integration
Strong Compatibility with Inductive Loads such as contactors and solenoids
Per-Channel LED Diagnostics simplify maintenance and fault detection
No Special Load Polarity Restrictions compared to transistor outputs
Software-Based Configuration reduces setup complexity
Robust Industrial Design suitable for continuous operation environments
Stable Performance in Mixed-Voltage Systems

Technical FAQs — Engineering-Level Insights

What is the main function of the IC697MDL710?
It provides relay-based switching of industrial field loads from PLC outputs.
How many output channels does it support?
It typically supports 16 relay output points.
What makes relay output different from transistor output?
Relay outputs provide mechanical isolation and can switch both AC and DC loads.
What types of loads can it control?
Solenoids, contactors, alarms, and general-purpose industrial devices.
Is each output electrically isolated?
Yes, each channel uses relay isolation for safe switching.
Can it handle inductive loads?
Yes, it is suitable for inductive and resistive loads.
Does it provide diagnostic indicators?
Yes, LED indicators show the status of each output channel.
Is configuration hardware-based?
No, it is configured via PLC software.
What is its installation method?
It is installed in a GE Series 90-70 rack system.
Is it still widely used today?
It is mainly used in legacy GE 90-70 systems but remains common in industrial retrofit applications.
