GE Fanuc IC695CHS016 16-slot Universal Backplane

Brand:GE Fanuc PLC
Item No.:IC695CHS016
Product Origin:USA
Product Dimensions:601*141*147mm
Product Weight:2.06 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

IC695CHS016 (1)IC695CHS016 (2)IC695CHS016 (4)IC695CHS016 (3)

Introduction

The IC695CHS016 16-slot Universal Backplane is a high-capacity rack platform engineered for demanding industrial automation systems. Designed to serve as the structural and electrical foundation of a modular control architecture, this backplane enables seamless integration of CPU, I/O, and communication modules within a single, organized chassis. Its universal slot design and industrial-grade construction make it a dependable choice for scalable control systems where stability, flexibility, and long-term reliability matter.

Technical Specifications

ItemSpecification
ModelIC695CHS016
Module CategoryUniversal Backplane
Slot Capacity16 slots
Bus ArchitecturePCI Bus and High-Speed Serial Bus
Hot-Swap CapabilitySupported
Supply Voltage24 VDC
Backplane Current600 mA @ 3.3 VDC / 240 mA @ 5 VDC
Mounting OrientationHorizontal
Installation TypePanel-mounted rack
Operating EnvironmentIndustrial control cabinets


Applications

The IC695CHS016 is widely used in automation systems that demand structured expansion and long-term operational stability, including:

  • Manufacturing production lines with high I/O density

  • Process control systems requiring modular scalability

  • Power generation and utility control panels

  • Water and wastewater treatment facilities

  • Machine control cabinets with mixed I/O and communication modules

Its 16-slot capacity allows system designers to consolidate functions while keeping future expansion simple and predictable.


Advantages

  • High Slot Density: Sixteen module positions reduce the need for multiple racks, saving cabinet space.

  • Universal Slot Design: Supports a mix of processing, I/O, and communication modules without slot restrictions.

  • Industrial Reliability: Built to withstand vibration, electrical noise, and continuous operation.

  • Service-Friendly Architecture: Hot-swap support minimizes downtime during maintenance or upgrades.

  • Clean System Layout: Organized backplane layout improves airflow and cable management inside the cabinet.


Technical FAQs

  1. How many modules can the IC695CHS016 support?
    It supports up to 16 modules in a single rack.

  2. Is this backplane compatible with different module types?
    Yes, it accepts CPU, I/O, and communication modules in universal slots.

  3. Does it support hot swapping of modules?
    Hot-swap functionality is supported for compatible modules.

  4. What mounting orientation is required?
    The backplane is designed for horizontal mounting only.

  5. What power source does the backplane require?
    It operates using a 24 VDC supply via the system power module.

  6. Can PCI and serial bus modules be mixed in one rack?
    Yes, the universal backplane supports both bus types simultaneously.

  7. Is it suitable for continuous industrial operation?
    Yes, it is engineered for long-term use in industrial environments.

  8. Does the backplane include grounding support?
    Integrated grounding points are provided for proper system earthing.

  9. Are empty slots allowed?
    Empty slots are permitted, though slot covers are recommended for protection.

  10. Is this backplane expandable beyond 16 slots?
    Expansion requires additional racks rather than extending this backplane.
