Overview
The ABB SC520M 3BSE016237R1 Submodule Carrier is a high-reliability control platform component designed for advanced industrial automation and distributed control systems. As part of ABB’s SC500/Advant architecture, this submodule carrier integrates a local CPU and supports modular expansion, enabling flexible system configuration for complex process environments.
Built for harsh and mission-critical applications, the SC520M is widely used in marine, energy, and heavy industry installations where system stability, communication integrity, and long lifecycle performance are essential.
Technical Specifications
| Parameter | Specification |
|---|
| Model | SC520M |
| Part Number | 3BSE016237R1 |
| Module Type | Submodule Carrier |
| System Compatibility | ABB Advant / SC500 Series |
| Processor | Integrated local CPU |
| Communication Protocols | MB300, MB300E, Ethernet |
| Power Supply | 24 V DC (dual input support) |
| Power Consumption | ≤ 45 W (typical operation) |
| Operating Temperature | -25°C to +70°C |
| Protection Level | IP20 (rear), IP66 (front panel in enclosure use) |
| Dimensions (L × W × H) | 291 × 30 × 300 mm |
| Weight | Approx. 0.742 kg |
Industrial Applications
The SC520M submodule carrier is designed for demanding environments where control reliability and system scalability are essential.
-
Marine propulsion and ship automation systems
-
Offshore oil & gas control platforms
-
Power generation and turbine control systems
-
Industrial process automation and distributed control systems (DCS)
-
Heavy manufacturing and continuous production lines
Its marine-certified design variant also makes it suitable for environments with vibration, humidity, and temperature fluctuations.
Technical FAQs
1. What is the main function of the SC520M module?
It acts as a submodule carrier that hosts control and communication modules within ABB automation systems.
2. Does it include a CPU?
Yes, it integrates a local CPU for distributed processing tasks.
3. Which ABB systems is it compatible with?
It is primarily used in ABB Advant and SC500 series architectures.
4. What communication protocols are supported?
MB300, MB300E, and Ethernet-based communication.
5. Is it suitable for marine environments?
Yes, a marine-certified version is designed for offshore and shipboard use.
6. What is its operating temperature range?
Typically -25°C to +70°C depending on configuration.
7. What is the module’s weight?
Approximately 0.742 kg.
8. Can it be used in retrofit projects?
Yes, it is commonly used in legacy system maintenance and modernization.
9. What type of mounting does it use?
It is designed for rack or cabinet integration.
10. Is it still widely available?
Yes, it remains available through industrial automation spare parts channels.
