Industrial Overview
The ABB RTU560 560CMG10 1KGT017600R001 Remote Terminal Unit is a high-performance substation automation device designed for real-time data acquisition, control, and communication in critical power infrastructure. As part of ABB’s RTU560 platform, this module functions as a powerful communication and control hub between field equipment and SCADA systems, ensuring reliable grid monitoring and efficient remote operations.
Built for demanding industrial environments, it supports multi-protocol communication, flexible I/O expansion, and long-term operational stability, making it a cornerstone component in modern digital substations and utility automation systems.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB |
| Model Number | 560CMG10 |
| Order Code | 1KGT017600R001 |
| Module Type | Remote Terminal Unit (RTU) |
| Series | RTU560 |
| Processor | Industrial-grade CPU (i.MX6 class) |
| Operating System | Embedded Linux |
| Memory | 512 MB RAM / 4 GB Flash (typical) |
| Communication Interfaces | Ethernet, RS-232, RS-485, USB |
| Protocol Support | IEC 60870-5-101/104, DNP3, Modbus, IEC 61850 |
| Power Supply | 24–220 V DC (variant dependent) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (H×W×D) | 150 × 60 × 160 mm |
| Weight | Approx. 0.95 kg |
| Mounting | DIN rail / control cabinet installation |
Application Fields
The RTU560 CMG10 is widely deployed in mission-critical energy and automation systems, including:
-
Substation automation and control systems
-
Power transmission and distribution networks
-
Renewable energy plant monitoring (solar / wind)
-
SCADA-based remote monitoring infrastructure
-
Industrial process control and utility systems
Its strong protocol compatibility allows seamless integration with intelligent electronic devices (IEDs) and modern grid management platforms.
Key Advantages
This RTU stands out for its combination of communication flexibility and industrial-grade reliability. It acts as a central intelligence node, collecting data from field devices and transmitting it securely to control centers in real time.
Its modular architecture supports system scalability, allowing utilities to expand automation capabilities without redesigning the entire infrastructure. The rugged design ensures stable performance in harsh electrical and environmental conditions, while the embedded Linux platform provides long-term software flexibility and upgrade potential.
In addition, its multi-protocol support significantly reduces integration complexity, making it a cost-efficient solution for large-scale automation projects.
Technical FAQs
1. What is the main function of the RTU560 CMG10?
It collects, processes, and transmits field data for SCADA and automation systems.
2. Which systems is it compatible with?
It integrates with ABB RTU560 platforms and various SCADA systems.
3. What communication protocols are supported?
IEC 60870-5-101/104, DNP3, Modbus, and IEC 61850.
4. Can it be used in substations?
Yes, it is designed specifically for substation automation.
5. Is it suitable for renewable energy plants?
Yes, it is widely used in solar and wind power monitoring systems.
6. What operating system does it use?
It runs on an embedded Linux OS.
7. How is it mounted?
It supports DIN rail or control cabinet installation.
8. What is its typical weight?
Approximately 0.95 kg.
9. Can it operate in harsh environments?
Yes, it is designed for industrial-grade temperature and vibration resistance.
10. Is it scalable?
Yes, it supports modular expansion and system integration.
