The ABB Bailey PHARPS32010000 Power Supply Module is a high-capacity unit designed for the ABB Bailey Infi 90 Distributed Control System (DCS). As part of the Modular Power System III (MPS III) architecture, it delivers stable multi-voltage DC power to controllers, I/O modules, and communication backplanes in complex automation environments.
This module is engineered for demanding process industries where continuous operation and electrical stability are essential. Its robust design supports high-current multi-rail outputs, making it suitable for large-scale control cabinets and mission-critical automation systems.
Technical Specifications Summary
| Parameter | Specification |
|---|
| Manufacturer | ABB (Bailey Controls) |
| Model | PHARPS32010000 |
| Module Type | Power Supply Module (MPS III) |
| System Compatibility | ABB Bailey Infi 90 / Net 90 |
| Output Voltages | 5V DC @ 60A, ±15V DC @ 3A, 24V DC @ 17A, 125V DC @ 2.3A |
| Output Power | High-capacity multi-rail industrial supply |
| Efficiency | ~80%+ typical |
| Protection Features | Overvoltage, overcurrent, short-circuit, thermal protection |
| Mounting Type | Rack-mounted / power chassis |
| Operating Temperature | -20°C to +70°C (industrial-grade range) |
| Dimensions (L×W×H) | 279 × 127 × 483 mm |
| Weight | Approx. 5.9 kg |
Application Scenarios
The PHARPS32010000 is commonly deployed in large industrial automation environments requiring stable and distributed power delivery:
-
Power generation and utility control systems
-
Oil & gas refining and upstream operations
-
Petrochemical and chemical processing plants
-
Large-scale manufacturing and automation lines
-
Legacy DCS modernization and system expansion projects
Its high-current output capability makes it particularly suitable for dense control racks where multiple subsystems operate simultaneously.
Engineering Advantages
The PHARPS32010000 is designed for high-density industrial power delivery, enabling it to support multiple voltage rails within a single module. This significantly reduces cabinet complexity and improves system organization.
A major advantage is its multi-output stability under heavy load conditions, allowing it to maintain consistent voltage even when multiple I/O modules and controllers draw fluctuating current.
It also features a rugged industrial design with strong thermal tolerance, supporting reliable operation in demanding environments with wide temperature variation. In many system configurations, it is also supported in hot-swappable and redundant architectures, improving uptime and maintainability.
Technical FAQs
1. What is the main function of PHARPS32010000?
It provides regulated multi-voltage DC power for ABB Bailey Infi 90 system components.
2. What outputs does it provide?
5V @ 60A, ±15V @ 3A, 24V @ 17A, and 125V DC @ 2.3A.
3. What system is it used in?
ABB Bailey Infi 90 / Net 90 DCS systems.
4. Is it a high-power module?
Yes, it is one of the higher-capacity MPS III power modules.
5. What is its weight?
Approximately 5.9 kg in typical configuration.
6. Can it support continuous operation?
Yes, it is designed for 24/7 industrial duty cycles.
7. Does it support redundancy?
Yes, in appropriate MPS III system configurations.
8. What protection features are included?
Overvoltage, overcurrent, short-circuit, and thermal protection.
9. How is it installed?
Mounted in an ABB Bailey rack or power chassis system.
10. What industries commonly use it?
Power generation, petrochemical, oil & gas, and heavy process industries.
