The ABB Bailey PHARPS11100000 Power Supply Module is a Modular Power System III (MPS III) unit designed for ABB Infi 90 distributed control environments. It functions as a high-reliability rack-mounted power assembly that delivers multiple regulated DC outputs to support controllers, I/O modules, and communication subsystems.
This model is typically used in legacy industrial automation systems where stable multi-voltage power distribution is essential for maintaining continuous process control. Its rugged architecture ensures dependable performance in long-life plant operations such as power generation and heavy process industries.
Technical Specifications Overview
| Parameter | Specification |
|---|
| Manufacturer | ABB (Bailey Controls) |
| Model | PHARPS11100000 |
| Module Type | Power Supply Assembly (MPS III) |
| System Compatibility | ABB Bailey Infi 90 / Net 90 |
| Input Voltage Range | 102–265 VAC / 102–270 VDC |
| Output Voltages | +5V, ±15V, +24V, +48V DC |
| Output Current Capacity | 5V @ 14A, 24V @ 6A, 48V @ 3A |
| Operating Temperature | 0°C to 70°C |
| Protection Features | Overcurrent, overvoltage, thermal protection |
| Mounting Type | Rack-mounted / modular chassis |
| Dimensions (L×W×H) | Approx. 216 × 89 × 135 mm |
| Weight | Approx. 3.6 kg |
Application Scenarios
The PHARPS11100000 is widely deployed in mission-critical industrial environments where uninterrupted power distribution is essential:
-
Power plant distributed control systems
-
Oil and gas refining automation
-
Petrochemical process control facilities
-
Water treatment and utility infrastructure
-
Large-scale industrial automation cabinets
Its multi-output design makes it suitable for mixed-load environments requiring different voltage rails within a single control rack.
Engineering Highlights
This module stands out for its multi-rail power architecture, allowing it to supply several voltage levels simultaneously without requiring multiple standalone power units. This reduces cabinet complexity and improves system reliability.
Its design supports industrial-grade stability across wide input ranges, making it tolerant of voltage fluctuations commonly found in heavy industrial sites. The internal regulation system ensures clean and stable output, which is critical for sensitive control electronics.
Another key strength is its high thermal endurance (up to 70°C operating range), enabling stable operation in demanding environments with limited cooling efficiency.
Technical FAQs
1. What is the main function of PHARPS11100000?
It provides regulated multi-voltage DC power for ABB Infi 90 control systems.
2. What outputs does it provide?
+5V, ±15V, +24V, and +48V DC outputs.
3. What is the input range?
It supports 102–265 VAC or 102–270 VDC input.
4. Is it compatible with modern PLC systems?
It is mainly used in legacy ABB Infi 90 / Net 90 DCS platforms.
5. What is the weight of the module?
Approximately 3.6 kg.
6. What is the operating temperature range?
0°C to 70°C under standard industrial conditions.
7. Does it support redundancy?
Yes, system-level redundancy can be configured in MPS III setups.
8. What type of mounting is used?
Rack-mounted modular power chassis installation.
9. What protections are built in?
Overcurrent, overvoltage, and thermal protection systems.
10. Where is it commonly used?
In continuous-process industries such as power generation and petrochemical plants.
