Industrial Overview
The ABB Bailey NTCU01 Interface Terminal Unit is a fundamental interface component used in the INFI 90 Distributed Control System (DCS). It is designed to provide a stable and organized termination point for field wiring, enabling seamless signal transfer between industrial field devices and INFI 90 control modules.
As part of ABB’s legacy automation architecture, the NTCU01 plays a critical role in simplifying complex wiring structures while maintaining high signal integrity and operational reliability. It is widely used in continuous process industries where long-term stability and maintenance efficiency are essential.
Technical Specifications
| Parameter | Details |
|---|
| Model | NTCU01 |
| System | ABB Bailey INFI 90 / Network 90 |
| Type | Interface Terminal Unit |
| Function | Field signal termination & interface point |
| Signal Type | Analog / Digital (system dependent) |
| Connected Modules | INFI 90 I/O and interface modules |
| Power Requirement | 24 VDC |
| Power Consumption | ~20–30 mA (low power design) |
| Mounting Type | Cabinet / termination panel mounted |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5%–95% non-condensing |
| Dimensions (HxWxD) | Approx. 203 × 51 × 178 mm |
| Weight | Approx. 0.3–0.6 kg |
Applications
The NTCU01 is widely deployed in industrial automation environments where structured field wiring and stable signal termination are required:
-
Oil & gas production and refining systems
-
Power generation and turbine control systems
-
Petrochemical and chemical processing plants
-
Water and wastewater treatment facilities
-
Industrial manufacturing automation systems
-
Legacy ABB Bailey INFI 90 system maintenance projects
It is especially valuable in environments requiring long lifecycle operation and simplified maintenance of complex I/O wiring networks.
Technical FAQs
1. What is the main function of the NTCU01?
It provides a structured interface and termination point for field signals in ABB INFI 90 systems.
2. What system is it used in?
It is used in ABB Bailey INFI 90 Distributed Control Systems.
3. What types of signals does it handle?
It supports analog and digital signals depending on system configuration.
4. What is its power requirement?
It operates on a 24 VDC supply with low current consumption.
5. What industries use this module?
Oil & gas, power generation, petrochemical, and water treatment industries.
6. Is it an active processing module?
No, it is a passive interface/termination unit.
7. What is its operating temperature range?
0°C to +70°C.
8. How is it installed?
It is mounted inside control cabinets on termination panels.
9. What is its main advantage?
It improves wiring organization and signal reliability in DCS systems.
10. Is it still used in modern automation systems?
It is mainly used in existing ABB INFI 90 legacy installations.
