ABB Bailey NTCL01 Termination Unit

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB Bailey NTCL01 Termination Unit

Name: ABB Bailey NTCL01 Termination Unit
Brand: ABB Bailey
SKU: 7576
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB Bailey
Item No.:NTCL01
Product Origin:Sweden (SE)
Product Dimensions:203 × 51 × 178 mm
Product Weight:0.3kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Industrial Overview

The ABB Bailey NTCL01 Termination Unit is a critical interface component within the INFI 90 Distributed Control System (DCS), designed to provide robust termination for INFI-NET® and Plant Loop communication networks.

It acts as the essential bridge between control modules and field communication loops, ensuring stable signal routing, accurate data transmission, and simplified wiring architecture inside industrial control cabinets. The NTCL01 is widely recognized for its reliability in long-life legacy automation systems still operating across global process industries.

Engineered for durability and ease of integration, this module supports both twinaxial and coaxial communication media, making it a flexible and dependable solution for industrial network termination requirements.

Technical Specifications

Parameter	Details
Model	NTCL01
System	ABB Bailey INFI 90 / Network 90
Type	Communication Link Termination Unit
Function	INFI-NET / Plant Loop termination interface
Communication Interface	Twinaxial / Coaxial cable support
Connected Modules	INNIS01, INLIM03, NKLS series (system dependent)
Power Requirement	24 VDC
Current Consumption	~15–25 mA (low power design)
Operating Temperature	0°C to 70°C
Storage Temperature	-40°C to 85°C
Humidity Range	5%–95% non-condensing
Mounting Type	Cabinet field termination panel
Dimensions (HxWxD)	Approx. 203 × 51 × 178 mm
Weight	Approx. 0.3 kg

Applications

The NTCL01 is widely used in installed ABB Bailey INFI 90 systems across multiple industries:

Oil & gas production and offshore platforms
Power generation and utility control systems
Petrochemical and refinery automation
Water and wastewater treatment plants
Industrial process manufacturing facilities
Legacy DCS maintenance and lifecycle support projects

It is especially important in systems requiring stable loop communication termination and reliable network integrity over long operational lifecycles.

Key Advantages

Stable Communication Loop Termination
Ensures reliable connection between INFI-NET networks and control modules.
Flexible Cable Compatibility
Supports both coaxial and twinaxial communication wiring.
Industrial-Grade Reliability
Designed for continuous operation in harsh industrial environments.
Low Power Consumption
Minimal 24VDC load improves overall system efficiency.
Simplified Maintenance Design
Easy configuration and straightforward cabinet installation.

Technical FAQs

1. What is the main function of the NTCL01?
It terminates INFI-NET or Plant Loop communication loops in ABB INFI 90 systems.

2. What systems is it compatible with?
It is used in ABB Bailey INFI 90 and Network 90 DCS platforms.

3. What type of cables does it support?
It supports coaxial and twinaxial communication cables.

4. What is its power requirement?
It operates on a 24 VDC supply with low current consumption.

5. What modules does it typically connect with?
It is commonly used with INNIS01 and related network interface modules.

6. Is it still used in modern automation systems?
It is mainly used in existing legacy INFI 90 installations.

7. What is the operating temperature range?
0°C to 70°C.

8. Is it a signal processing module?
No, it is a termination interface module for communication loops.

9. How is it installed?
It is mounted inside control cabinets on field termination panels.

10. What is its main benefit in DCS systems?
It ensures stable and noise-resistant communication loop termination.
