The ABB Bailey NTCF01 Termination Unit is a key interface component used in the INFI 90 Distributed Control System (DCS). It is designed to provide reliable electrical termination and signal conditioning between field wiring and control system modules, ensuring stable communication and accurate signal transfer in complex industrial automation environments.
Built for long-term industrial operation, the NTCF01 plays a crucial role in simplifying field connections while maintaining signal integrity across harsh process conditions such as vibration, electrical noise, and temperature variation.
Technical Specifications
| Parameter | Details |
|---|
| Model | NTCF01 |
| System | ABB Bailey INFI 90 |
| Type | Termination Unit |
| Function | Signal termination for control system I/O |
| Power Requirement | +24 VDC, approx. 50 mA |
| Communication Interface | RS-485 (system dependent configuration) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | Field termination panel mounted |
| Dimensions (HxWxD) | Approx. 178 × 158 × 38 mm |
| Weight | Approx. 0.4 kg |
Applications
The NTCF01 termination unit is widely used in ABB Bailey INFI 90 systems across multiple industries:
-
Oil & gas production and refining facilities
-
Power generation plants
-
Petrochemical processing units
-
Water and wastewater treatment systems
-
Industrial manufacturing automation
-
Large-scale distributed control systems (DCS)
It is especially important in installations requiring stable field-to-controller signal interfacing under continuous industrial operation.
Technical FAQs
1. What is the main function of the NTCF01?
It provides termination and interface connections between field wiring and INFI 90 control modules.
2. What system is it used in?
It is used in ABB Bailey INFI 90 Distributed Control Systems.
3. What is the power requirement?
It typically operates on +24 VDC with low current consumption.
4. What communication interface does it support?
It supports RS-485 communication depending on system configuration.
5. What industries use this module?
It is used in oil & gas, power generation, chemical plants, and water treatment systems.
6. What is its operating temperature range?
It operates between -20°C and +70°C.
7. Is it suitable for harsh environments?
Yes, it is designed for industrial environments with vibration and electrical noise.
8. How is it installed?
It is mounted on a field termination panel inside the control cabinet.
9. What is its approximate weight?
Around 0.4 kg.
10. Is it still used in modern systems?
Yes, it is commonly found in installed legacy ABB INFI 90 systems still operating in industry.
