Honeywell 900H01-0102 Relay Output Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Honeywell 900H01-0102 Relay Output Module

Name: Honeywell 900H01-0102 Relay Output Module
Brand: Honeywell DCS
SKU: 7549
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Honeywell DCS
Item No.:900H01-0102
Product Origin:USA
Product Dimensions:100 x 72 x 120 mm
Product Weight:0.3kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Product Overview

The Honeywell 900H01-0102 Relay Output Module is a rugged and highly reliable discrete output solution designed for the ControlEdge HC900 / ControlEdge 900 automation platform. It delivers precise switching control for industrial field devices, enabling safe and efficient operation of alarms, motors, solenoids, and interlocking systems.

Engineered with electromechanical relay technology and strong galvanic isolation, this module is optimized for demanding process environments where dependable switching performance and electrical separation are essential for operational stability and safety.

Technical Specifications

Parameter	Details
Model	900H01-0102
Platform	ControlEdge HC900 / 900
Module Type	Relay Output Module
Output Channels	8 relays (4 Form-A + 4 Form-C)
Output Type	Electromechanical relay
Voltage Rating	120/240 VAC or 30 VDC
Current Rating	4 A resistive load per channel
Lamp Load Rating	0.5 A (incandescent)
Isolation	Galvanic isolation (logic to field)
Response Time	ON ≤ 10 ms / OFF ≤ 10 ms
Power Consumption	5V backplane ~110 mA / 24V ~100 mA
Status Indicators	LED per channel + module diagnostics
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Dimensions (HxWxD)	Approx. 100 x 72 x 120 mm
Weight	Approx. 0.25–0.7 kg (depending configuration)

Application Areas

The 900H01-0102 module is widely used across industries requiring dependable switching of electrical loads:

Power generation and distribution systems
Oil & gas processing plants
Chemical and petrochemical facilities
Water and wastewater treatment systems
HVAC and building automation systems
Industrial machinery and OEM equipment

Its relay-based output structure makes it especially suitable for direct interface with high-voltage field devices and mixed-load applications.

Key Advantages

Flexible Relay Architecture
Combination of Form-A and Form-C contacts allows adaptable control strategies.
High Load Handling Capability
Supports up to 4A resistive loads for industrial-grade devices.
Strong Electrical Isolation
Galvanically isolated outputs improve system safety and reduce electrical interference.
Clear Diagnostic Feedback
LED indicators provide real-time channel and system status visibility.
Reliable Industrial Design
Built for long-term operation in continuous process environments.

Technical FAQs

1. What type of outputs does this module provide?
It provides 8 electromechanical relay outputs, including Form-A and Form-C contacts.

2. What loads can it control?
It can switch up to 120/240 VAC or 30 VDC devices depending on application.

3. What is the maximum current per channel?
Up to 4A resistive load per relay channel.

4. Is the module electrically isolated?
Yes, it uses galvanic isolation between control logic and field outputs.

5. What is the switching speed?
Approximately 10 ms ON and 10 ms OFF response time.

6. Can it handle inductive loads?
Yes, but external suppression (diodes/snubbers) is recommended.

7. How many outputs are available?
The module provides 8 discrete relay outputs.

8. How is module status displayed?
Through individual channel LEDs and diagnostic indicators.

9. Is it suitable for continuous operation?
Yes, it is designed for industrial continuous-duty environments.

10. How is installation performed?
It is installed directly into the ControlEdge HC900 rack system.
