Product Perspective
The Honeywell 900G01-0102 Digital Input Module is a dependable signal acquisition solution within the ControlEdge HC900 architecture, purpose-built for capturing discrete field inputs with high stability and accuracy. Designed to meet the expectations of modern process industries, this module ensures consistent communication between field devices and control systems.
Its compact footprint and robust electrical design make it particularly suitable for installations where reliability, space efficiency, and long-term operational consistency are essential. Whether deployed in new automation projects or retrofitted systems, it delivers dependable performance across demanding environments.
Technical Specifications
| Parameter | Details |
|---|
| Model | 900G01-0102 |
| Platform | ControlEdge HC900 |
| Module Type | Digital Input Module |
| Input Channels | 16 (Single-ended) |
| Input Type | Contact Closure |
| Input Voltage | 24 VDC System Supply |
| Controller Supplied Voltage | ~15 VDC Loop Supply |
| Switching Current | 2.6 mA nominal |
| Response Time | ON ≤ 4 ms / OFF ≤ 6 ms |
| Isolation | Galvanic Isolation |
| Indicators | Per-channel LED + module status LEDs |
| Power Consumption | 5V: 130 mA / 24V: 40 mA |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Dimensions (HxWxD) | Approx. 140 x 38 x 145 mm |
| Weight | Approx. 0.3 – 0.7 kg |
Industry Applications
The 900G01-0102 module is widely used in systems requiring precise monitoring of discrete signals:
-
Process control in chemical and petrochemical plants
-
Power generation and energy distribution systems
-
Water treatment and environmental monitoring
-
Food and beverage production lines
-
Pharmaceutical manufacturing environments
-
OEM equipment and industrial machinery
Its ability to reliably interpret field signals makes it a critical component in automation systems where accuracy directly impacts operational performance.
Technical FAQs
1. What type of inputs does the 900G01-0102 support?
It supports contact-based digital inputs such as switches, relays, and push buttons.
2. How many input channels are available?
The module provides 16 independent input channels.
3. What voltage does the module operate on?
It operates on a 24 VDC system supply with an internal loop supply of approximately 15 VDC.
4. Is electrical isolation included?
Yes, galvanic isolation is provided between field inputs and internal circuitry.
5. What is the typical response time?
Up to 4 ms for ON and 6 ms for OFF transitions.
6. Can it be used in harsh industrial environments?
Yes, it is designed for standard industrial temperature ranges and conditions.
7. How is module status indicated?
Through LED indicators for each channel and overall module diagnostics.
8. Does it require complex configuration?
No, it integrates easily into the HC900 system with minimal setup.
9. What devices can be connected?
Dry contact devices including limit switches, relays, and push buttons.
10. How is the module installed?
It is mounted directly into the HC900 I/O rack.
