Product Overview and Industrial Role
The ABB PPD113 B03 R2060 (3BHE023584R2060) AC800 Control Module is a high-performance process and power automation control unit designed for ABB’s AC 800PEC platform. It is engineered to handle both high-speed power electronic control tasks and complex process automation logic, making it a core component in advanced industrial control architectures.
This module is widely used in environments where real-time responsiveness, system stability, and precision control are critical, especially in energy and heavy industrial applications.
Technical Specifications
| Parameter | Details |
|---|
| Product Type | AC800 Control / Process Control Module |
| Manufacturer | ABB |
| Model | PPD113 B03 R2060 |
| Part Number | 3BHE023584R2060 |
| Control Platform | ABB AC 800PEC |
| Function | High-speed process & power control |
| Processing Type | Real-time hybrid CPU + FPGA architecture |
| Control Cycle | Down to microsecond-level (application dependent) |
| Communication | CEX bus, ModuleBus, industrial fieldbus support |
| I/O Compatibility | ABB S800 I/O system |
| Programming Tool | ABB Control Builder M (IEC 61131-3) |
| Power Supply | Industrial DC system supply (rack dependent) |
| Operating Temperature | -25°C to +70°C |
| Installation Type | Rack-mounted modular design |
| Weight | Approx. 4.5–5.5 kg |
| Dimensions | Approx. 130 mm × 110 mm × 45 mm |
Applications
The ABB PPD113 B03 R2060 module is commonly deployed in:
-
Power generation control systems
-
Synchronous generator excitation systems
-
Hydro, thermal, and gas turbine plants
-
Industrial automation and process control lines
-
Renewable energy conversion systems
-
Metallurgy and heavy manufacturing control systems
-
Traction and transportation power systems
It is especially effective in high-speed power regulation environments requiring stable closed-loop control.
Technical FAQs
1. What is the main function of this module?
It manages high-speed process and power control tasks in ABB AC 800PEC systems.
2. Is it a PLC?
No, it is a specialized control module used in ABB’s advanced automation architecture.
3. Where is it commonly used?
Power plants, industrial automation systems, and energy conversion applications.
4. What systems is it compatible with?
ABB AC 800PEC and S800 I/O systems.
5. What makes it different from standard controllers?
It supports hybrid CPU + FPGA architecture for ultra-fast control cycles.
6. Can it handle real-time control?
Yes, it is specifically designed for real-time industrial applications.
7. Is it suitable for power generation systems?
Yes, it is widely used in generator and excitation control systems.
8. What communication interfaces does it support?
CEX bus, ModuleBus, and multiple industrial fieldbus protocols.
9. What is its typical lifespan?
Designed for long-term industrial continuous operation.
10. Is it still widely used today?
Yes, especially in installed ABB legacy and active AC 800PEC systems.
