Engineered Signal Intelligence for Modern Automation
The ABB PFBK164 3BSE000469R1 Signal Processing Board is a precision-focused module developed to enhance data accuracy and real-time responsiveness in industrial control systems. Designed for seamless integration within ABB automation architectures, it acts as a critical interface between field sensors and control logic.
With advanced signal conditioning and multi-channel processing capabilities, this board ensures that even complex analog and digital signals are converted into stable, actionable data. Its rugged industrial design and high-speed processing make it an excellent choice for applications where accuracy and reliability directly impact production performance.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | ABB |
| Model | PFBK164 |
| Part Number | 3BSE000469R1 |
| Module Type | Signal Processing Board |
| Operating Voltage | 24 V DC / 100–240 V AC (depending on setup) |
| Input Current | ≤100 mA |
| Output Current | ≤100 mA |
| Signal Channels | Up to 16 channels |
| Processor Speed | Approx. 100 MHz |
| Memory | 1 MB Flash / 32 KB RAM |
| Communication Protocols | EtherCAT, DeviceNet, Profinet, RS-485 |
| Operating Temperature | -20°C to +60°C (up to +70°C) |
| Storage Temperature | -40°C to +85°C |
| Dimensions (H × W × D) | Approx. 160 × 100 × 35 mm |
| Weight | Approx. 0.25 – 0.47 kg |
Real-World Industrial Applications
The PFBK164 Signal Processing Board is widely applied in industries requiring precise measurement and control:
-
Web tension control systems in paper, foil, and textile production
-
Process automation systems requiring accurate sensor data acquisition
-
Power and energy systems for monitoring and regulation
-
Manufacturing lines with real-time feedback control
-
Drive and motion systems requiring stable signal interpretation
Its ability to process high-frequency signals with minimal latency ensures optimal performance in dynamic industrial environments.
Competitive Advantages and Value
This module is designed not only for performance but also for long-term operational stability, making it a reliable component in critical automation systems.
-
High-precision signal conditioning improves data integrity
-
Multi-channel architecture supports complex system requirements
-
Strong resistance to electrical noise and interference
-
Compact design optimizes cabinet space
-
Advanced diagnostics simplify maintenance and troubleshooting
By improving signal clarity and reducing system noise, the PFBK164 directly contributes to enhanced process efficiency and reduced downtime.
Technical FAQs
1. What is the primary role of the PFBK164 board?
It processes and conditions analog and digital signals for accurate system control.
2. How many signal channels does it support?
Up to 16 channels for multi-point data acquisition.
3. Is it compatible with ABB DCS systems?
Yes, it integrates with ABB automation platforms including AC systems.
4. What industries commonly use this module?
Paper, textile, energy, and general manufacturing industries.
5. Can it handle high-frequency signals?
Yes, it is designed for fast and precise signal processing.
6. What communication protocols are available?
It supports EtherCAT, DeviceNet, Profinet, and RS-485.
7. Is it suitable for harsh environments?
Yes, it operates reliably in industrial temperature ranges and noisy environments.
8. Does it support sensor integration?
Yes, it interfaces with various industrial sensors and field devices.
9. What maintenance is required?
Minimal—routine inspection and diagnostics monitoring are sufficient.
10. Can it be used for retrofit projects?
Yes, it is commonly used for system upgrades and replacements.
