The Bently Nevada 3500/40M-01-00 176449-01 3500/40M Proximitor Monitor is a high-performance four-channel monitoring module designed to deliver accurate vibration and shaft position measurements for critical rotating machinery. As an integral component of the Bently Nevada 3500 Machinery Protection System, it continuously processes signals from proximity transducers, providing real-time condition monitoring and dependable machinery protection.
Engineered for continuous industrial service, this monitor enables operators to detect abnormal operating conditions at an early stage, reducing unexpected downtime and improving maintenance planning. Its flexible configuration, reliable alarm management, and proven monitoring capabilities make it a trusted solution across a wide range of industrial applications.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Bently Nevada |
| Model | 3500/40M-01-00 |
| Spare Part Number | 176449-01 |
| Product Type | Proximitor Monitor |
| Series | 3500 Machinery Protection System |
| Monitoring Channels | 4 Independent Channels |
| Input Type | Proximity Transducer Signals |
| Measurement Functions | Radial Vibration, Thrust Position, Differential Expansion, Eccentricity, REBAM |
| Alarm Functions | Programmable Alert and Danger Setpoints |
| Power Consumption | Typical 7.7 W |
| Installation | Full-Height Rack Module |
| Compatible System | Bently Nevada 3500 Rack |
| Main Module Dimensions | 241.3 × 24.4 × 241.8 mm |
| Main Module Weight | Approximately 0.91 kg |
| I/O Module Dimensions | 241.3 × 24.4 × 99.1 mm |
| I/O Module Weight | Approximately 0.20 kg |
Where It Excels
The 3500/40M-01-00 monitor is widely implemented in facilities where continuous asset monitoring is essential for operational safety and equipment longevity. By providing precise measurements of shaft dynamics and vibration behavior, it supports predictive maintenance strategies that help prevent costly failures.
Typical applications include:
-
Steam turbine monitoring
-
Gas turbine protection
-
Centrifugal compressor supervision
-
Industrial pumps and blowers
-
Large electric motors
-
Power generation plants
-
Oil and gas production facilities
-
Petrochemical refineries
-
Chemical processing plants
-
Mining and heavy manufacturing industries
Performance Advantages
The 3500/40M-01-00 combines advanced monitoring technology with industrial-grade durability, making it an excellent choice for demanding machinery protection applications.
Key benefits include:
-
Four high-precision monitoring channels
-
Continuous real-time machinery condition monitoring
-
Accurate vibration and shaft position measurement
-
Flexible configuration for multiple measurement types
-
User-programmable alarm and shutdown functions
-
Excellent compatibility with Bently Nevada proximity transducers
-
Fast response to abnormal machinery conditions
-
Reliable long-term performance in harsh environments
-
Simplified installation within the 3500 rack system
-
Helps minimize maintenance costs and maximize equipment uptime
Technical FAQs
1. What is the primary purpose of the 3500/40M-01-00 monitor?
It continuously monitors vibration and shaft position by processing signals from proximity transducers, providing early warning of machinery faults.
2. How many monitoring channels are available?
The module provides four independent monitoring channels that can be configured for different machinery protection functions.
3. Which measurements can this monitor perform?
It supports radial vibration, thrust position, differential expansion, eccentricity, and REBAM measurements depending on the selected configuration.
4. What is spare part number 176449-01?
176449-01 is the spare monitor assembly for the Bently Nevada 3500/40M Proximitor Monitor, allowing straightforward replacement during maintenance.
5. Can alarm levels be customized?
Yes. Alert and Danger alarm setpoints can be individually configured using the 3500 Rack Configuration Software to match specific machinery protection requirements.
6. Which sensors are compatible with this monitor?
The module is designed to operate with compatible Bently Nevada proximity transducers used for vibration and shaft position monitoring.
7. Is the module suitable for continuous industrial operation?
Yes. It is engineered for 24-hour continuous monitoring in demanding industrial environments where reliability is critical.
8. What are the physical dimensions and weight?
The main module measures 241.3 × 24.4 × 241.8 mm and weighs approximately 0.91 kg. The associated I/O module measures 241.3 × 24.4 × 99.1 mm and weighs approximately 0.20 kg.
9. What are the advantages of continuous vibration monitoring?
Continuous monitoring helps detect developing mechanical issues early, supports predictive maintenance, improves equipment reliability, and reduces unplanned shutdowns.
10. Why choose the 3500/40M-01-00 176449-01 Proximitor Monitor?
Its combination of measurement accuracy, configurable protection functions, dependable operation, and seamless integration with the 3500 Machinery Protection System makes it an outstanding solution for safeguarding valuable rotating assets.
