Bently Nevada 330171-10-38-10-02 3300 5 mm Proximity Probes

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Bently Nevada 330171-10-38-10-02 3300 5 mm Proximity Probes

Name: Bently Nevada 330171-10-38-10-02 3300 5 mm Proximity Probes
Brand: Bently Nevada PLC
SKU: 10049
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Bently Nevada PLC
Item No.:330171-10-38-10-02
Product Origin:USA
Product Dimensions: Total Length:1 meter
Product Weight:0.3kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Product Overview

The Bently Nevada 330171-10-38-10-02 is a 3300 5 mm Proximity Probe designed for accurate shaft vibration, shaft position, Keyphasor®, and speed measurement on small rotating machinery where limited installation space requires a compact probe. It is part of the 3300 5 mm Proximity Transducer System, which consists of a 330171 probe, a 3300 XL extension cable, and a 3300 XL Proximitor® Sensor. Together, these components provide a calibrated eddy-current transducer system suitable for continuous machinery condition monitoring.

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Part Number	330171-10-38-10-02
Product Type	3300 5 mm Proximity Probe
Probe Diameter	5 mm
Measurement Technology	Eddy-current, non-contact
Thread Type	1/4-28 UNF (without armor)
Unthreaded Length	1.0 in (25.4 mm)
Overall Case Length	3.8 in (96.5 mm)
Total Probe Cable Length	1.0 m (3.3 ft)
Connector	Miniature coaxial ClickLoc connector (standard cable)
Agency Approval	Not specified in this abbreviated part number*
Compatible Extension Cable	3300 XL Extension Cable
Compatible Sensor	3300 XL Proximitor® Sensor

Typical Applications

The 330171-10-38-10-02 is commonly used for:

Steam turbines
Gas turbines
Centrifugal compressors
Small motors
Pumps
Gearboxes
Expanders
Keyphasor® and speed measurement systems

It is suitable for:

Radial shaft vibration
Shaft position
Speed sensing
Phase reference (Keyphasor®)
Machinery protection and condition monitoring

Key Features

Compact 5 mm eddy-current probe for installations with limited mounting space.
Measures both dynamic shaft vibration and static shaft position.
Fully compatible with 3300 XL extension cables and 3300 XL Proximitor® Sensors.
Stable measurement performance over a wide operating temperature range.
Gold-plated ClickLoc connector for secure electrical connection.
Designed for interchangeability without individual field calibration when used as a complete transducer system.

Frequently Asked Questions

1. What is the 330171-10-38-10-02 used for?

It is used for non-contact measurement of shaft vibration, shaft position, rotational speed, and Keyphasor® signals on rotating machinery.

2. What does the "38" option indicate?

It specifies an overall probe case length of 3.8 inches.

3. What cable length is supplied?

The 10 option indicates a 1.0-meter (3.3-foot) probe cable.

4. Is this an armored probe?

No. Model 330171 is the standard non-armored version. The armored version uses the 330172 model number.

5. Which connector does it use?

It uses a Miniature coaxial ClickLoc connector (Option 02).

6. Does this probe work by itself?

No. It is designed to operate as part of the complete 3300 5 mm Transducer System, together with a compatible extension cable and Proximitor® Sensor.

7. Can it measure both vibration and position?

Yes. The complete transducer system measures both dynamic vibration and static shaft position.

8. Which machines commonly use this probe?

It is widely installed on turbines, compressors, pumps, motors, and other critical rotating machinery where compact probes are required.
