Designed for High-Performance Rotating Equipment
The 330103-00-06-10-02-05 operates by generating an eddy current field that measures the distance between the probe tip and a conductive shaft surface. This produces an output signal proportional to shaft movement, allowing highly accurate monitoring of both dynamic vibration and static position. When paired with a compatible 3300 XL Extension Cable and 3300 XL Proximitor® Sensor, it forms a complete machinery protection solution capable of supporting predictive maintenance and equipment diagnostics.
Typical equipment includes:
-
Steam turbines
-
Gas turbines
-
Centrifugal compressors
-
Electric motors
-
Pumps
-
Generators
-
Gearboxes
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Bently Nevada |
| Model Number | 330103-00-06-10-02-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Series | 330103 Metric Series |
| Measurement Principle | Non-contact Eddy Current |
| Mounting Thread | M10 × 1 Metric |
| Probe Diameter | 8 mm |
| Unthreaded Length | 0 mm |
| Overall Case Length | 60 mm |
| Total Cable Length | 1.0 m (3.3 ft) |
| Connector Type | Miniature Coaxial ClickLoc™ Connector |
| Cable Type | Standard Cable |
| Agency Approval | Option 05 – CSA / ATEX / IECEx |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Housing Material | AISI 303/304 Stainless Steel |
| Seal Material | Viton® O-ring |
| Compatible Extension Cable | 3300 XL Extension Cable |
| Compatible Sensor | 3300 XL Proximitor® Sensor |
| Operating Temperature | Approx. -51°C to +177°C |
| Approximate Dimensions | Ø8 mm × 60 mm case length |
| Approximate Weight | 0.323 kg |
Industrial Applications
The 330103-00-06-10-02-05 is widely deployed for continuous condition monitoring of high-value rotating assets.
| Industry | Typical Equipment |
|---|
| Power Generation | Steam turbines, generators, gas turbines |
| Oil & Gas | Compressors, pumps, turbo expanders |
| Petrochemical | Process compressors and rotating machinery |
| Manufacturing | High-speed motors, gearboxes, production lines |
| Marine | Propulsion and auxiliary rotating equipment |
Typical monitoring applications include:
-
Shaft vibration measurement
-
Radial displacement monitoring
-
Axial position measurement
-
Rotor eccentricity analysis
-
Machine protection systems
-
Predictive maintenance programs
Performance Advantages
Certified for Hazardous Locations
With Agency Approval Option 05, this probe supports installations requiring CSA, ATEX, and IECEx certifications, making it suitable for demanding industrial environments.
Precision Eddy Current Technology
The non-contact sensing principle provides highly repeatable measurements without mechanical wear, ensuring long-term stability and reliable machinery diagnostics.
Rugged Stainless-Steel Construction
Its stainless-steel housing, PPS probe tip, and Viton® sealing offer excellent resistance to vibration, oil, moisture, and elevated temperatures commonly found in industrial facilities.
Flexible Installation
The 60 mm probe body combined with the 1.0-meter cable provides convenient installation flexibility while maintaining compatibility with standard 3300 XL transducer systems.
Proven System Compatibility
Designed to integrate seamlessly with 3300 XL Extension Cables and 3300 XL Proximitor Sensors, the probe simplifies maintenance while ensuring measurement consistency across existing monitoring systems.
Technical FAQs
1. What is the 330103-00-06-10-02-05 used for?
It measures shaft vibration, radial displacement, and axial position on rotating machinery using non-contact eddy current technology.
2. Which transducer system is this probe designed for?
It is part of the Bently Nevada 3300 XL 8 mm Proximity Transducer System.
3. What mounting thread does this probe use?
It features an M10 × 1 metric mounting thread.
4. What does the "06" option indicate?
It specifies a 60 mm overall probe case length.
5. What does the "10" option represent?
It designates a 1.0-meter (3.3 ft) integral cable.
6. What connector is used?
The probe is supplied with a Miniature Coaxial ClickLoc™ connector and standard cable.
7. What does Agency Approval Option "05" mean?
It indicates the probe is configured with CSA, ATEX, and IECEx approvals for hazardous-area applications.
8. What materials are used in the probe?
The sensing tip is made from Polyphenylene Sulfide (PPS), while the housing is manufactured from AISI 303/304 stainless steel with a Viton® O-ring seal.
9. Is this probe compatible with existing 3300 XL monitoring systems?
Yes. It is fully compatible with matching 3300 XL Extension Cables and 3300 XL Proximitor Sensors.
10. Which machines commonly use this probe?
It is widely installed on turbines, compressors, pumps, generators, motors, and other critical rotating equipment requiring continuous condition monitoring.
