Product Overview
Reliable Shaft Measurement with Proven 3300 XL Technology
The 330103-00-05-10-02-05 uses eddy current measurement technology to detect the gap between the probe tip and the rotating shaft surface. The resulting electrical signal allows monitoring systems to evaluate shaft movement, vibration amplitude, and positional changes with high precision.
Designed for continuous industrial operation, this proximity probe supports applications such as:
-
Shaft radial vibration monitoring
-
Rotor displacement measurement
-
Axial position monitoring
-
Turbine supervisory systems
-
Compressor protection
-
Predictive maintenance programs
The probe’s metric mounting design allows easier installation on internationally manufactured machinery while maintaining compatibility with existing Bently Nevada 3300 XL monitoring platforms.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Bently Nevada |
| Model Number | 330103-00-05-10-02-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Series | 3303 Metric Series |
| Mounting Thread | M10 x 1 Metric Thread |
| Probe Design | Non-Armored Metric Probe |
| Measurement Technology | Eddy Current Non-Contact Sensing |
| Probe Tip Diameter | 8 mm |
| Unthreaded Length | 0 mm |
| Overall Case Length | 50 mm |
| Cable Length | 1.0 m (3.3 ft) |
| Connector Type | Miniature Coaxial ClickLoc™ Connector |
| Cable Type | Standard Cable |
| Approval Configuration | CSA / ATEX / IECEx |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Sealing Material | Viton® O-ring |
| Compatible Extension Cable | 3300 XL Extension Cable |
| Compatible Sensor | 3300 XL Proximitor Sensor |
| Probe Diameter | 8 mm |
| Approximate Dimensions | Ø8 mm × 50 mm case length |
| Approximate Weight | 0.323 kg |
Applications
Built for Mission-Critical Industrial Equipment
The 330103-00-05-10-02-05 is widely used in industries where machinery reliability and operational safety are essential.
| Industry | Typical Equipment |
|---|
| Power Generation | Steam turbines, gas turbines, generators |
| Oil & Gas | Centrifugal compressors, pumps, expanders |
| Petrochemical | Process rotating machinery |
| Manufacturing | Motors, gearboxes, high-speed drives |
| Marine | Propulsion and auxiliary systems |
Common application areas include:
-
Online machinery condition monitoring
-
Shaft vibration analysis
-
Rotor position measurement
-
Equipment protection systems
-
Maintenance optimization
Advantages
Metric Installation Compatibility
The M10 x 1 mounting thread provides excellent compatibility with metric equipment designs, allowing straightforward replacement and installation in global industrial applications.
Accurate Non-Contact Monitoring
The eddy current sensing principle eliminates physical contact between the probe and rotating shaft, reducing mechanical wear and providing consistent measurement performance during continuous operation.
Extended 50 mm Probe Body
The 50 mm case length offers additional mounting flexibility for applications requiring a longer probe configuration while preserving the measurement characteristics of the 3300 XL 8 mm platform.
Durable Industrial Construction
The PPS probe tip and stainless-steel housing provide strong resistance against mechanical stress, temperature variation, and harsh operating conditions.
Secure ClickLoc™ Connection
The miniature coaxial ClickLoc™ connector provides reliable connection performance and simplifies maintenance activities in industrial vibration monitoring systems.
Technical FAQs
1. What is the Bently Nevada 330103-00-05-10-02-05 used for?
It is used for non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
2. Which monitoring system does this probe belong to?
It belongs to the Bently Nevada 3300 XL 8 mm Proximity Transducer System.
3. What thread type does this probe use?
The probe uses an M10 x 1 metric thread for installation.
4. Is the probe armored?
No. The 330103 series is the non-armored metric version of the 3300 XL 8 mm proximity probe family.
5. What does the "00" option represent?
The first option indicates a 0 mm unthreaded length configuration.
6. What does the "05" case length option indicate?
It specifies a 50 mm overall probe case length.
7. What does the "10" option indicate?
It indicates a 1.0-meter total probe cable length.
8. What connector is used on this model?
It uses a Miniature Coaxial ClickLoc™ connector with standard cable.
9. What material is the probe tip made from?
The probe tip uses Polyphenylene Sulfide (PPS) material for durability and stable sensing performance.
10. Which machines commonly use this proximity probe?
It is commonly installed on turbines, compressors, generators, pumps, motors, and other rotating machinery requiring continuous condition monitoring.
