Reliable Condition Monitoring with Enhanced Cable Protection
The 330102-00-60-50-01-05 combines proven eddy current sensing technology with an armored cable construction, making it an excellent choice for machinery where monitoring electronics are installed farther from the probe location.
Typical monitoring capabilities include:
-
Shaft radial vibration measurement
-
Rotor displacement monitoring
-
Shaft position measurement
-
Bearing condition analysis
-
Rotor eccentricity monitoring
-
Turbine Supervisory Instrumentation (TSI)
-
Continuous machine protection
Designed to integrate seamlessly with the complete 3300 XL 8 mm Transducer System, the probe supports high-accuracy measurements that comply with API 670 performance requirements when used with compatible components.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Bently Nevada |
| Model Number | 330102-00-60-50-01-05 |
| Product Type | 3300 XL 8mm Proximity Probe |
| Probe Series | 330102 (Armored) |
| Measurement Technology | Non-Contact Eddy Current |
| Probe Diameter | 8 mm |
| Mounting Thread | 3/8-24 UNF |
| Unthreaded Length | 0.0 in |
| Overall Case Length | 6.0 in |
| Total Cable Length | 5.0 m (16.4 ft) |
| Cable Construction | Stainless Steel Armored |
| Connector | Miniature Coaxial ClickLoc™ Connector with Connector Protector |
| Cable Type | Standard Cable |
| Agency Approval | Option 05 – CSA, ATEX, IECEx |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Housing Material | AISI 303/304 Stainless Steel |
| Compatible Extension Cable | 3300 XL Extension Cable |
| Compatible Sensor | 5 m 3300 XL Proximitor Sensor |
| Operating Temperature | Approximately -51°C to +177°C |
| Approximate Dimensions | 8 mm probe diameter × 6.0 in case length |
| Approximate Weight | 0.75 kg |
Typical Applications
Designed for Critical Industrial Assets
The 330102-00-60-50-01-05 is widely deployed on rotating equipment where accurate shaft movement monitoring is essential for maximizing equipment availability and minimizing unplanned downtime.
| Industry | Typical Equipment |
|---|
| Power Generation | Steam turbines, gas turbines, generators |
| Oil & Gas | Compressors, pumps, expanders |
| Petrochemical | Centrifugal compressors |
| Mining | Crushers, mills, conveyors |
| Heavy Manufacturing | Motors, blowers, gearboxes, fans |
Typical applications include:
-
Continuous shaft vibration monitoring
-
Rotor displacement analysis
-
Axial position measurement
-
Machinery protection systems
-
Predictive maintenance programs
-
Online condition monitoring
Product Benefits
Extended 5-Meter Cable Configuration
The integrated 5-meter cable simplifies installations where monitoring equipment is located a considerable distance from the measurement point, reducing additional cable management requirements.
Heavy-Duty Armored Protection
The stainless-steel armored cable enhances durability and provides excellent resistance to mechanical wear, vibration, and harsh industrial environments.
High Measurement Accuracy
Advanced eddy current technology delivers repeatable, non-contact measurements that support effective machinery diagnostics and long-term reliability.
Certified for Hazardous Locations
The Option 05 approval package includes CSA, ATEX, and IECEx certifications, allowing installation in a wide range of hazardous industrial environments.
Seamless System Compatibility
Designed for full compatibility with 3300 XL Extension Cables, 5-meter Proximitor Sensors, and Bently Nevada monitoring systems, ensuring straightforward installation and dependable operation.
Technical FAQs
1. What is the primary function of this probe?
It provides precise non-contact measurement of shaft vibration, displacement, and rotor position on rotating machinery.
2. What does the "330102" designation indicate?
It identifies the armored version of the 3300 XL 8 mm proximity probe with a stainless-steel armored cable.
3. What does the "60" option represent?
It specifies a 6.0-inch overall case length.
4. What does the "50" option indicate?
It specifies a 5.0-meter (16.4 ft) total cable length.
5. Which Proximitor Sensor should be used?
It should be paired with a 5-meter 3300 XL Proximitor Sensor, as 5-meter probes are calibrated specifically for 5-meter systems.
6. Is the cable armored?
Yes. The probe features a durable stainless-steel armored cable for enhanced mechanical protection.
7. What hazardous-area approvals are included?
The Option 05 configuration includes CSA, ATEX, and IECEx approvals.
8. What connector does this probe use?
It is equipped with a Miniature Coaxial ClickLoc™ connector with connector protector.
9. Which industries commonly use this model?
It is widely used in power generation, oil and gas, petrochemical, mining, and heavy industrial manufacturing.
10. Can this probe be integrated into existing 3300 XL monitoring systems?
Yes. It is fully compatible with the 3300 XL 8 mm Proximity Transducer System when matched with the correct extension cable and Proximitor Sensor.
