Product Introduction
The Yokogawa SAV144-S63 Analog Input Module is a 16-channel analog input module designed for Yokogawa modular I/O platforms. It is developed for receiving voltage-based analog signals and providing a stable interface between field instruments and Yokogawa automation architectures.
The SAV144-S63 belongs to the SAV144 analog input series and supports 1 to 5 V / 1 to 10 V input signals with module isolation. The S63 specification includes a signal cable interface adapter and is designed for use with Yokogawa-specific cable connections, providing a compact and organized installation solution for industrial applications.
With its 16-channel configuration, isolated input structure, and compatibility with Yokogawa modular systems, the SAV144-S63 is suitable for equipment expansion, replacement projects, and long-term industrial installation requirements.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Yokogawa |
| Model | SAV144-S63 |
| Product Type | Analog Input Module |
| Module Series | SAV144 |
| Number of Input Channels | 16 channels |
| Input Signal Type | Voltage Input |
| Input Range | 1 to 5 V DC / 1 to 10 V DC |
| Input Structure | Module Isolation |
| Signal Connection | Yokogawa-Specific Cable Interface |
| Connection Adapter | Signal Cable Interface Adapter |
| Compatible Cable | Yokogawa SAV144 Dedicated Cable |
| Environmental Compatibility | ISA Standard G3 |
| Operating Temperature | -20°C to +70°C |
| Installation Method | Modular Rack Installation |
| Power Consumption | Approx. 5 V DC / 24 V DC supply from module base |
| Dimensions (Approx.) | 32.8 × 130 × 107.5 mm |
| Approximate Weight | 0.35 kg |
Typical Applications
The Yokogawa SAV144-S63 Analog Input Module is suitable for industrial environments requiring reliable voltage signal acquisition and compact I/O integration.
Typical application areas include:
-
Oil and gas facilities
-
Petrochemical plants
-
Chemical processing industries
-
Power generation facilities
-
Water treatment projects
-
Manufacturing plants
-
Process industry installations
-
Industrial equipment modernization projects
-
Yokogawa I/O cabinet expansion applications
The module’s isolated 16-channel design provides an efficient solution for installations where multiple analog signals require organized connection and dependable performance.
Key Features & Benefits
The SAV144-S63 Analog Input Module provides several advantages:
-
16-channel analog input configuration
-
Supports 1 to 5 V and 1 to 10 V voltage signals
-
Module isolation design
-
Compatible with Yokogawa dedicated signal cables
-
Compact modular structure
-
Supports high-density I/O installation
-
ISA Standard G3 environmental compatibility
-
Wide temperature operating range
-
Suitable for replacement and expansion projects
-
Designed for stable industrial signal processing
Technical FAQs
1. What is the Yokogawa SAV144-S63?
The SAV144-S63 is a 16-channel analog input module designed for Yokogawa modular I/O platforms.
2. What type of signals does the SAV144-S63 support?
The module supports voltage input signals including 1 to 5 V DC and 1 to 10 V DC.
3. How many input channels does the SAV144-S63 provide?
The module provides 16 analog input channels.
4. Does the SAV144-S63 have channel isolation?
Yes. The module uses a module isolation structure designed for reliable signal interface performance.
5. What connection method is used by the SAV144-S63?
The S63 version uses a signal cable interface adapter compatible with Yokogawa-specific cable connections.
6. What is the operating temperature range?
The SAV144-S63 supports approximately -20°C to +70°C operating conditions.
7. Which systems are compatible with the SAV144-S63?
The module is designed for compatible Yokogawa modular I/O platforms, including related ProSafe-RS architectures.
8. What are the dimensions of the SAV144-S63?
The approximate dimensions are 32.8 × 130 × 107.5 mm.
9. What is the weight of the SAV144-S63?
The approximate weight is 0.35 kg.
10. Why choose the Yokogawa SAV144-S63?
The SAV144-S63 combines 16-channel voltage input capability, isolated module design, compact construction, and Yokogawa compatibility, making it a practical choice for industrial I/O expansion and replacement applications.
