Advanced Vibration Measurement for Continuous Asset Monitoring
The Bently Nevada 330101-00-20-20-11-05 3300 XL 8 mm Proximity Probe is a high-performance non-contact sensor designed for continuous vibration and shaft position monitoring of rotating machinery. As part of the industry-proven 3300 XL Series, this probe delivers excellent measurement accuracy, long-term stability, and reliable performance in demanding industrial environments.
This configuration features a 0 mm unthreaded length, a 2.0 in (50.8 mm) case length, a 2.0 m (6.6 ft) total cable length, a Miniature Coaxial ClickLoc connector with FluidLoc cable, and CSA, ATEX, and IECEx agency approvals. Designed to operate with compatible 3300 XL Proximitor® sensors and extension cables, it provides dependable monitoring for critical equipment where equipment availability and operational reliability are priorities.
Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 330101-00-20-20-11-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Probe Diameter | 8 mm |
| Unthreaded Length | 0 mm |
| Case Length | 2.0 in (50.8 mm) |
| Total Cable Length | 2.0 m (6.6 ft) |
| Thread Size | 3/8-24 UNF |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Cable Option | FluidLoc Cable |
| Agency Approvals | CSA, ATEX, IECEx |
| Probe Case Material | Stainless Steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Approximate Dimensions | Ø8 mm × 50.8 mm Case Length |
| Approximate Weight | Approximately 0.32 kg |
