Accurate Rotational Reference Measurement for Critical Machinery Protection Systems
The Bently Nevada 330500-01-02 3300 XL Series Keyphasor® Probe is a precision rotational reference sensor designed for high-speed rotating equipment monitoring applications. It provides a once-per-revolution pulse signal that serves as a timing reference for vibration analysis, phase measurements, shaft speed monitoring, and rotor dynamic diagnostics. Keyphasor technology is fundamental in advanced machinery protection systems because it synchronizes all dynamic vibration measurements to the exact shaft position.
Engineered for mission-critical industrial environments, this probe integrates seamlessly with Bently Nevada monitoring systems, helping maintenance teams detect imbalance, misalignment, shaft instability, and other developing mechanical issues before they become major failures.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Keyphasor® Probe |
| Model Number | 330500-01-02 |
| Series | 3300 XL Series |
| Primary Function | Shaft speed and rotational phase reference measurement |
| Sensing Technology | Eddy current proximity sensing |
| Measurement Type | Once-per-revolution pulse generation |
| Compatible Systems | Bently Nevada 3300 XL monitoring platforms |
| Target Surface | Shaft notch, keyway, or marker |
| Signal Output | Keyphasor timing pulse |
| Installation Type | Fixed industrial mounting |
| Housing Material | Industrial stainless steel construction |
| Operating Temperature | -51°C to +177°C (system dependent) |
| Protection Design | Industrial sealed configuration |
| Dimensions | Approx. 80 × 25 × 25 mm |
| Weight | Approx. 0.30 kg |
Industrial Applications
The 330500-01-02 is widely used in rotating equipment protection systems where precise shaft synchronization is essential.
Typical applications include:
-
Steam turbines
-
Gas turbines
-
Industrial compressors
-
Centrifugal pumps
-
Generators
-
Gearboxes
-
Large electric motors
-
Blowers and fans
-
LNG and petrochemical plants
-
Power generation facilities
It is particularly valuable in systems that require synchronized vibration analysis across multiple measurement channels.
Key Advantages
Precise Rotational Reference Signal
Generates highly accurate timing pulses for phase analysis and rotor diagnostics.
Improved Machinery Diagnostics
Helps engineers identify imbalance, misalignment, looseness, and resonance conditions earlier.
Seamless 3300 XL Integration
Designed to work within Bently Nevada's machinery protection ecosystem.
Industrial-Grade Reliability
Built for continuous operation in harsh industrial environments.
Enhanced Predictive Maintenance
Supports advanced condition monitoring strategies that reduce unplanned downtime.
Long Operational Lifespan
Solid industrial construction delivers dependable long-term performance.
Technical FAQs
1. What is a Keyphasor® probe?
It is a rotational reference sensor that generates a pulse every shaft revolution.
2. Why is a Keyphasor signal important?
It synchronizes vibration measurements with shaft position for accurate diagnostics.
3. What equipment commonly uses this probe?
Turbines, compressors, generators, motors, and other rotating machinery.
4. Does it measure vibration directly?
No. It provides rotational timing information rather than vibration measurements.
5. What target does the probe detect?
It detects a notch, keyway, or other physical reference point on a rotating shaft.
6. Is it compatible with Bently Nevada monitoring systems?
Yes. It is designed for integration with Bently Nevada machinery protection platforms.
7. Can it support shaft speed calculations?
Yes. The timing pulse can be used to calculate rotational speed.
8. Is professional installation required?
Yes. Proper mounting and gap adjustment are essential for accurate operation.
9. Can it operate continuously?
Yes. It is engineered for permanent industrial installation.
10. Is this technology still widely used?
Yes. Keyphasor technology remains a standard component in advanced turbomachinery monitoring systems.
