Introduction
The Honeywell CC‑PUIO31 51454220‑176 Universal I/O Module is a versatile signal interface designed for the Honeywell C300 distributed control system (DCS). This module combines analog, digital, and pulse I/O capabilities in a single unit, enabling flexible connection of a wide range of field devices—including sensors, switches, and actuators—into the control network. Built to handle demanding industrial conditions, the CC‑PUIO31 enhances signal integration efficiency, simplifies system architecture, and supports real‑time process monitoring and control.
Technical Specifications
| Specification | Details |
|---|---|
| Model | CC‑PUIO31 (51454220‑176) |
| Product Type | Universal I/O Module |
| System Compatibility | Honeywell C300 Distributed Control Systems |
| Supported I/O | Analog, digital, and pulse I/O channels |
| Analog Input Types | 4–20 mA, 0–10 V |
| Analog Output Types | 4–20 mA, 0–10 V |
| Digital Inputs | Logic‑level discrete inputs |
| Digital Outputs | Logic‑level discrete outputs |
| Pulse Inputs | High‑speed pulse signal support |
| Resolution | 16‑bit for analog signals |
| Accuracy | ±0.1 % of full scale (analog) |
| Isolation | Channel‑to‑system electrical isolation |
| Operating Voltage | 24 V DC nominal |
| Operating Temperature | −20 °C to +70 °C |
| Humidity Range | 5 % to 95 % non‑condensing |
| Mounting | Rack or backplane installation |
| Dimensions (L × W × H) | Approx. 160 mm × 25 mm × 100 mm |
| Weight | Approx. 0.48 kg |
