Introduction
The ABB 3HAC14549-3/10A Rectifier Module is a high-reliability industrial power conversion unit designed for ABB robotic and automation drive systems. It provides stable AC-to-DC rectification for motion control architectures, ensuring consistent energy delivery to servo drives and robot controllers in demanding production environments.
Engineered for continuous-duty industrial use, this rectifier supports stable voltage regulation, reduced electrical noise, and high-efficiency power conversion, making it a critical component in ABB robotics and automation power systems.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB |
| Model Number | 3HAC14549-3/10A |
| Product Type | Rectifier Module (AC/DC Power Conversion) |
| System Compatibility | ABB Robotics / Drive Systems |
| Input Voltage | 380–480 V AC, 3-phase |
| Output Current | 10 A (rated configuration) |
| Output Type | Stabilized DC bus supply |
| Efficiency | Up to 98% (system dependent) |
| Frequency Range | 40–60 Hz |
| Protection Class | IP21 / IP22 (cabinet installation) |
| Cooling Method | Forced air / cabinet ventilation |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Mounting Type | Panel / drive cabinet mounting |
| Electrical Isolation | Industrial-grade reinforced isolation |
| Dimensions (H×W×D) | 300 mm × 150 mm × 120 mm |
| Weight | ~2.2 kg |
Applications
The ABB 3HAC14549-3/10A Rectifier is widely used in industrial automation systems requiring stable DC power supply:
-
ABB industrial robot power supply systems
-
Servo drive and motion control cabinets
-
Automotive welding and assembly robots
-
CNC machine auxiliary drive systems
-
Packaging and material handling automation
-
Factory production line robotics
-
High-precision positioning systems
-
Industrial control cabinet power conversion
Technical FAQs
Q1: What is the main function of this rectifier module?
A: It converts three-phase AC power into stable DC power for ABB robotic and drive systems.
Q2: What is the rated output current?
A: The module is designed for approximately 10A output configuration.
Q3: Which systems is it compatible with?
A: It is used in ABB robotics systems and industrial drive cabinets.
Q4: Is it suitable for continuous operation?
A: Yes, it is designed for 24/7 industrial continuous-duty environments.
Q5: What type of installation is required?
A: It is mounted inside industrial control or drive cabinets.
Q6: What is the input voltage range?
A: Typically 380–480V AC, three-phase input.
Q7: Does it support overload protection?
A: Yes, system-level protection is implemented through ABB drive architecture.
Q8: What industries commonly use it?
A: Automotive manufacturing, robotics, CNC machining, and industrial automation.
Q9: Is cooling required?
A: Yes, it relies on cabinet airflow or forced-air cooling.
Q10: What makes it reliable in industrial environments?
A: Its ABB-grade power electronics design ensures stable conversion, low ripple output, and long-term durability.
