Introduction
The ABB 3HNM00148-01 is a compact industrial servo motor designed for precision motion control applications in ABB robotic and automation systems. It is typically used in ABB robot axes, auxiliary motion units, and small-to-medium industrial automation mechanisms, where accurate positioning, fast response, and stable torque output are required.
This motor belongs to ABB’s high-precision servo family and is engineered for continuous duty operation in robotic environments, supporting dynamic acceleration, deceleration, and repeatable positioning with high reliability.
It is commonly associated with ABB industrial robots and automation cells where space efficiency and motion accuracy are critical.
Technical Specifications
The ABB 3HNM00148-01 servo motor is a low-voltage, high-speed precision motor optimized for robotic motion systems.
| Parameter | Specification |
|---|---|
| Model | 3HNM00148-01 |
| Type | Servo Motor (Industrial / Robotics) |
| Rated Voltage | 24 V DC |
| Rated Current | ~2.5 A |
| Rated Power | ~50 W |
| Rated Speed | up to 3000 RPM |
| Continuous Torque | ~0.1 Nm |
| Encoder | 512 PPR incremental feedback |
| Insulation Class | F |
| Protection Class | IP20 |
| Operating Temperature | -10°C to +40°C |
| Mounting Type | Flange-mounted |
| Shaft Diameter | ~10 mm |
| Brake Option | Optional DC brake (variant dependent) |
