Introduction
The ABB UNC 4672A V1 (HIEE205012R0001) Analog Measuring Card is a high-precision industrial data acquisition and signal processing module used in ABB control, drive, and automation systems. It is designed to collect, condition, and process multiple analog and digital signals from field devices, enabling accurate monitoring and stable control in complex industrial environments.
This module is commonly applied in power generation systems, turbine control platforms, and heavy industrial automation, where reliable measurement accuracy and real-time signal handling are essential for system stability and performance.
Technical Specifications
The UNC 4672A V1 functions as an analog measurement and interface module with multi-channel input capability and embedded signal processing functions.
| Parameter | Specification |
|---|
| Model | UNC 4672A V1 |
| ABB Order Number | HIEE205012R0001 |
| Type | Analog Measuring / Data Acquisition Card |
| Function | Signal measurement & processing |
| Input Channels | Analog inputs + digital I/O (configuration dependent) |
| Output Functions | Relay / control / sensor power outputs (system dependent) |
| Communication | Serial / fieldbus interfaces (system dependent) |
| Resolution | Up to 16-bit (application dependent) |
| Power Supply | 24 V DC |
| Installation | Rack / cabinet-mounted industrial module |
Applications
The ABB UNC 4672A V1 Analog Measuring Card is widely used in industrial automation and power system environments requiring precise measurement and control feedback:
-
Turbine and generator monitoring systems
-
Power plant control and protection systems
-
Industrial drive and motor control systems
-
Process automation and distributed control systems (DCS)
-
Signal acquisition in energy management systems
-
Heavy industry monitoring (steel, cement, mining)
-
Legacy ABB control and measurement architectures
Its ability to handle multiple input types makes it suitable for complex multi-variable monitoring tasks.
Advantages
The UNC 4672A V1 provides robust performance in industrial measurement applications where accuracy and reliability are critical.
-
High-precision analog signal acquisition for stable system monitoring
-
Multi-channel input capability for complex industrial processes
-
Strong compatibility with ABB automation platforms
-
Reliable operation in electrically noisy environments
-
Supports real-time monitoring and fast data processing
-
Designed for long lifecycle industrial use
-
Stable performance under continuous-duty conditions
-
Flexible integration into existing ABB control systems
Technical FAQs
1. What is the main function of the UNC 4672A V1 card?
It collects and processes analog measurement signals in ABB industrial systems.
2. Is it a controller?
No, it is a measurement and interface module, not a standalone controller.
3. Where is it commonly used?
In power plants, turbines, and industrial automation systems.
4. What type of signals does it handle?
Analog inputs, digital signals, and system-dependent control outputs.
5. Is it still used in modern systems?
It is mainly found in installed base and legacy ABB systems.
6. What is its typical weight?
Approximately 1.0 to 2.5 kg depending on configuration.
7. Does it support digital communication?
Yes, via system-dependent communication interfaces.
8. Is it suitable for harsh environments?
Yes, it is designed for industrial-grade conditions.
9. Does it require calibration?
Usually configured during system commissioning rather than frequent recalibration.
10. Can it be replaced with modern modules?
Yes, but only through compatible ABB upgrade pathways.
