Introduction
The ABB UA D215 A102 3BHE026284R0102 PEC80 Converter Signal Interface is a high-precision industrial interface module designed for ABB PEC80-based power electronics and excitation control systems. It is engineered to manage signal conversion between control electronics and power conversion stages, ensuring stable communication, accurate feedback processing, and reliable system synchronization.
This module is commonly used in high-power industrial environments such as generator excitation systems, large motor drives, and heavy process automation. Its primary function is to act as a critical bridge between control logic and converter hardware, enabling precise regulation of voltage, current, and system protection parameters.
Technical Specifications
The UA D215 A102 operates as a dedicated signal interface unit within ABB PEC80 control architectures, supporting robust industrial-grade signal processing.
| Parameter | Specification |
|---|
| Model | UA D215 A102 |
| ABB Material Number | 3BHE026284R0102 |
| Type | Converter Signal Interface Module |
| System Platform | ABB PEC80 / excitation control systems |
| Function | Signal conversion & interface processing |
| Input Signals | Analog and digital system feedback |
| Output Signals | Control, gating, and reference signals |
| Communication | Internal system bus architecture |
| Power Supply | 24 V DC system dependent |
| Installation | Control cabinet / rack-mounted module |
Applications
The ABB UA D215 A102 PEC80 Converter Signal Interface is widely deployed in high-performance industrial systems requiring precise electrical control and monitoring.
-
ABB PEC80 excitation control systems
-
Synchronous generator excitation and regulation units
-
High-power industrial motor drive systems
-
Power conversion and rectifier control systems
-
Metallurgy and heavy manufacturing automation
-
Industrial energy management systems
-
Legacy ABB excitation and converter cabinets
It is especially important in systems where stable excitation control directly impacts grid stability and machine performance.
Advantages
The UA D215 A102 is designed to ensure high reliability and precise signal handling in demanding industrial environments.
-
High-accuracy signal conversion for stable system control
-
Strong compatibility with ABB PEC80 architectures
-
Reliable performance under high electrical noise conditions
-
Compact modular design for easy cabinet integration
-
Supports stable excitation and converter operation
-
Long operational lifespan in continuous-duty systems
-
Improved system response and reduced signal latency
-
Robust industrial-grade construction for harsh environments
Technical FAQs
1. What is the main function of the UA D215 A102 module?
It converts and manages signals between control systems and power converter hardware.
2. Which ABB system is it used in?
It is primarily used in ABB PEC80 excitation and converter systems.
3. Is it a standalone controller?
No, it functions as an interface module within a larger control system.
4. What type of signals does it handle?
It handles analog and digital feedback and control signals.
5. Is it used in power plants?
Yes, especially in generator excitation systems.
6. What is its weight?
Approximately 0.4 kg depending on configuration.
7. Can it be used in modern systems?
It is mostly found in installed-base PEC80 systems.
8. Does it require external cooling?
No, it relies on cabinet-level cooling design.
9. Is it critical for system stability?
Yes, it plays a key role in maintaining stable excitation and converter control.
10. Can it be replaced with newer modules?
Yes, but only within compatible ABB upgrade architectures.
