Product Overview and Engineering Perspective

The Yokogawa F3XD16-3F DC Input Module is purpose-built for reliable digital signal acquisition within the FA-M3 PLC system. Designed with precision and durability in mind, it enables seamless integration of field devices by converting DC input signals into stable digital data for control processing. Its compact footprint and consistent performance make it a preferred choice for engineers seeking efficiency without compromising system integrity.

Technical Specifications

ParameterDetails
ManufacturerYokogawa
ModelF3XD16-3F
Module TypeDC Input Module
Input Channels16
Input TypeDC Voltage (Sink/Source)
Rated Input Voltage24 V DC
Operating Voltage Range20.4 – 26.4 V DC
Input Current4.1 mA per point
Response Time62.5 μs to 16 ms
IsolationPhotocoupler Isolation
Current Consumption65 mA (5 V DC)
Connection TypeTerminal Block (M3.5 screw)
Operating Temperature0°C to 55°C
Dimensions (H×W×D)110 × 80 × 20 mm
WeightApprox. 0.17 – 0.20 kg


Application Scenarios

The F3XD16-3F is widely deployed in industrial automation systems where accurate digital input monitoring is essential. It is commonly used in assembly lines, packaging systems, semiconductor manufacturing, and machine control applications. Its ability to process multiple discrete signals simultaneously makes it particularly effective in high-density control panels and distributed I/O configurations.


Performance Advantages and Highlights

This module offers a balance of speed, reliability, and compact design. Its photocoupler isolation protects against electrical noise and enhances system stability in harsh environments. The flexible response time allows adaptation to both high-speed and standard input requirements. Additionally, its compatibility with sink and source input configurations simplifies system design and reduces engineering complexity.

The low power consumption contributes to overall system efficiency, while the robust construction ensures long-term operational reliability in continuous industrial use.
