The ABB PD D200 A101 (3BHE019633R0101) Control Board is a high-performance industrial control module designed for precise regulation, monitoring, and coordination within complex automation and power systems. Commonly deployed in excitation systems, DCS architectures, and process control environments, it acts as a central processing and signal management unit.
Engineered with advanced processing capability and robust industrial design, this control board ensures stable system operation, efficient data handling, and seamless integration into ABB automation ecosystems. It is particularly valued in applications where accuracy, reliability, and continuous operation are critical.
Technical Specifications
| Parameter | Details |
|---|
| Model | PD D200 A101 |
| Part Number | 3BHE019633R0101 |
| Manufacturer | ABB |
| Module Type | Control Board / Processor Module |
| Input Voltage | 100–240 V AC |
| Output Voltage | 24 V DC |
| Output Current Capacity | Up to 100 A |
| Digital I/O | 16 inputs / 8 outputs |
| Communication Interface | RS485 / Modbus RTU |
| Processor Speed | ~800 MHz – 1 GHz |
| Memory | 4–8 GB (flash) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | Approx. 200 × 105 × 55 mm |
| Weight | Approx. 0.44 – 0.6 kg |
| Mounting | Cabinet / rack installation |
Applications
The PD D200 A101 control board is widely used in industrial environments where high-performance control and system coordination are required. Typical applications include:
-
Power plant excitation and voltage control systems
-
Distributed control systems (DCS) and SCADA platforms
-
Industrial process automation lines
-
Converter and drive control systems
-
Oil & gas and energy infrastructure
-
High-demand manufacturing operations
Its flexibility allows it to function both as a central controller and as an interface between subsystems, improving overall automation efficiency.
Advantages
One of the standout features of this module is its integrated control and power handling capability, allowing it to manage both logic processing and system-level power distribution. This reduces the need for additional hardware and simplifies cabinet design.
Its high-speed processor architecture ensures fast data processing and real-time control, which is essential in applications such as excitation systems and synchronized industrial operations. The inclusion of multiple communication protocols enables smooth integration with existing ABB and third-party systems.
The module is also designed for industrial durability, with strong resistance to temperature fluctuations and electrical interference. Combined with built-in diagnostics and monitoring features, it supports predictive maintenance and minimizes system downtime.
Overall, it delivers a balanced combination of performance, scalability, and long-term reliability for critical automation environments.
Technical FAQs
1. What is the main function of the PD D200 A101 control board?
It manages control logic, signal processing, and system coordination in industrial automation systems.
2. What voltage input does it support?
It supports a wide AC input range from 100 to 240 V.
3. What output does it provide?
It provides a regulated 24 V DC output for system components.
4. How many I/O channels are available?
It includes 16 digital inputs and 8 digital outputs.
5. What communication protocols are supported?
It supports RS485 and Modbus RTU communication.
6. Is it suitable for excitation systems?
Yes, it is commonly used in generator excitation and power control systems.
7. What is the processor performance level?
It uses a high-speed processor in the 800 MHz to 1 GHz range.
8. Can it operate in harsh environments?
Yes, it is designed for industrial conditions with a wide temperature range.
9. How is it installed?
It is typically mounted in a control cabinet or rack system.
10. Does it support system integration?
Yes, it integrates with ABB DCS systems and third-party automation platforms.
