GE IC697MDL750 Discrete Output Module

Brand:GE Fanuc PLC
Item No.:IC697MDL750
Product Origin:USA
Product Dimensions:320 × 200 × 70 mm
Product Weight:1kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

IC697MDL750-4IC697MDL750-1IC697MDL750-2IC697MDL750-3

Product Perspective

The GE IC697MDL750 Discrete Output Module is built for high-density digital output control within the Series 90-70 PLC platform. Engineered to handle multiple field devices simultaneously, it combines efficient signal switching with dependable electrical isolation. This module is particularly valuable in complex automation systems where performance consistency and scalable output capacity are essential for streamlined operations.

Technical Specifications

ParameterDetails
ModelIC697MDL750
SeriesSeries 90-70
Module TypeDiscrete Output Module
Output Points32 (4 groups of 8)
Rated Voltage24 / 48 V DC
Output Voltage Range20 – 60 V DC
Output Current0.5 A per point
Group Current2 A per group
Inrush Current10 A (20 ms)
Response Time1 ms (ON/OFF)
Output Voltage Drop≤ 1 V
Leakage Current1 mA max
Isolation Voltage1500 V (backplane), 500 V between groups
Backplane Current0.25 A
Dimensions320 × 200 × 70 mm
WeightApprox. 1.0 – 2.0 kg
MountingRack-based (VME standard)


Application Scenarios

The IC697MDL750 is designed for industrial environments requiring high channel density and reliable output control. It is frequently deployed in automotive manufacturing, energy systems, material handling, and process automation. Its ability to drive multiple loads—such as solenoids, pilot lights, and motor starters—makes it ideal for distributed I/O architectures and centralized PLC systems.


Core Strengths

This module delivers a strong balance between output density and operational reliability. With 32 output channels in a single slot, it reduces cabinet space while maintaining structured wiring through grouped outputs. Fast 1 ms switching ensures accurate control timing, while robust isolation protects system integrity in electrically noisy environments.

Its design also emphasizes maintainability. The removable terminal block simplifies installation and service, while clear channel grouping improves troubleshooting efficiency. For systems requiring consistent performance under continuous operation, the IC697MDL750 provides a dependable and scalable solution.


Technical FAQs

1. How many outputs are available on this module?
It provides 32 discrete outputs divided into four groups of eight.

2. What voltage does the module support?
It operates at 24/48 V DC with an output range of 20–60 V DC.

3. What is the current rating per output?
Each output supports up to 0.5 A continuous current.

4. How fast is the switching response?
The module has a maximum ON/OFF response time of 1 ms.

5. Is electrical isolation provided?
Yes, 1500 V isolation to the backplane and 500 V between groups.

6. What types of devices can it control?
It can drive solenoids, relays, motor starters, and indicator lights.

7. What is the inrush current capability?
Up to 10 A for short-duration startup loads.

8. Does it support grouped protection?
Yes, outputs are arranged in groups, simplifying protection and wiring.

9. How is it installed?
It mounts into a Series 90-70 rack using a VME-based backplane.

10. What is the power consumption from the backplane?
Approximately 0.25 A from the 5V bus.
