Product Introduction
The Honeywell RM7800L1087 Burner Control is a microprocessor-based flame safeguard and burner management controller from the Honeywell 7800 Series, designed for single-burner industrial combustion systems. It provides fully automated control of ignition sequencing, flame monitoring, purge cycles, valve proving, and safety interlocks for gas, oil, or combination fuel applications.
This model is widely used in industrial boilers, furnaces, and process heating systems where enhanced safety logic, valve proving capability, and advanced diagnostics are required. It is part of Honeywell’s modular burner control ecosystem, supporting plug-in flame amplifiers, purge cards, and keyboard/display modules for flexible system configuration.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | Honeywell |
| Series | 7800 Series Burner Control |
| Model | RM7800L1087 |
| Control Type | Microprocessor-based burner management system |
| Application | Single burner (gas / oil / combination fuel) |
| Power Supply | 120 VAC, 50/60 Hz |
| Operating Temperature | -40°C to +60°C |
| Power Consumption | Up to 10W (typical system class) |
| Flame System | Compatible with Honeywell flame amplifiers & detectors |
| Valve Proving | Supported (VPS configuration options) |
| Display Interface | S7800A keyboard/display module support |
| Diagnostics | Lockout history, sequence status, fault codes |
| Safety Functions | Flame failure lockout, interlock monitoring |
| Architecture | Modular relay + purge timer + amplifier system |
Functional Overview
The RM7800L1087 manages the complete combustion lifecycle in a structured and safety-driven sequence:
-
Pre-purge of combustion chamber
-
Ignition and pilot flame establishment
-
Main flame transition and stabilization
-
Continuous flame monitoring during operation
-
Post-purge for safe shutdown conditions
-
Valve proving sequence (before/after/both modes selectable)
Its internal microprocessor ensures precise timing control and repeatable safety behavior across every operating cycle.
Key Advantages
-
Advanced Valve Proving System (VPS): Enhances safety by verifying fuel valve integrity before ignition
-
Fully Automated Burner Sequencing: Manages purge, ignition, flame proving, and shutdown cycles
-
High Safety Integrity Design: Immediate lockout response during unsafe flame conditions
-
Modular Expansion Capability: Supports plug-in amplifiers, purge cards, and communication modules
-
Strong Diagnostic Capability: Stores multiple fault histories for fast troubleshooting
-
Industrial Reliability: Designed for continuous operation in harsh combustion environments
This combination makes it a strong choice for applications requiring both safety compliance and operational flexibility.
Technical FAQs
1. What is the main function of RM7800L1087?
It controls burner ignition, flame supervision, valve proving, and safety shutdown sequencing.
2. What types of fuel does it support?
Gas, oil, and combination fuel systems.
3. What is valve proving used for?
It verifies that fuel valves are not leaking before burner ignition for enhanced safety.
4. Does it include a display module?
Yes, it supports the S7800A keyboard/display interface for diagnostics.
5. What is its operating temperature range?
-40°C to +60°C.
6. Does it support post-purge operation?
Yes, post-purge timing can be configured for safe shutdown ventilation.
7. Can it store fault history?
Yes, it retains lockout and diagnostic records in non-volatile memory.
8. Is it suitable for continuous industrial use?
Yes, it is designed for industrial-duty burner systems.
9. What improves its safety performance?
Flame supervision, interlocks, and valve proving logic.
10. Why is it widely used?
Because it combines programmable burner sequencing with high-integrity safety control.
