OVATION 5X00846G01 Analog output modules

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

OVATION 5X00846G01 Analog output modules

Name: OVATION 5X00846G01 Analog output modules
Brand: Ovation DCS
SKU: 6454
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Ovation DCS
Item No.:5X00846G01
Product Origin:USA
Product Dimensions:125 × 35 × 160 mm
Product Weight:0.3kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

High‑Resolution Analog Output for Precision Control

The Ovation 5X00846G01 Analog Output Module is engineered to provide accurate and stable analog signal transmission within Emerson Ovation Distributed Control Systems (DCS). It delivers high‑resolution output channels that translate control decisions into precise current or voltage levels for field devices such as control valves, actuators, and regulators.

Designed for demanding industrial environments, this module ensures consistent analog performance with excellent signal fidelity, robust electrical isolation, and seamless integration into standard Ovation rack architectures.

Technical Specifications

Parameter	Specification
Manufacturer	Emerson Ovation
Model	5X00846G01
Module Type	Analog Output Module
Output Channels	8 analog outputs
Output Signal	4–20 mA current loop or configurable voltage outputs
Resolution	Up to 16‑bit
Output Accuracy	±0.1 % of full scale
Load Drive Capability	Up to 800 Ω per channel
Update Rate	5–10 ms per channel
Isolation	Channel‑to‑backplane isolation
Backplane Interface	Standard Ovation rack connector
Power Supply	Rack backplane powered
Operating Temperature	0 °C to 55 °C
Storage Temperature	–40 °C to 70 °C
Humidity	5 % to 95 % non‑condensing
Dimensions (HxWxD)	Approx. 125 × 35 × 160 mm
Weight	Approx. 0.30 kg
Mounting	Rack slot installation

Applications

The 5X00846G01 Analog Output Module is commonly used in process and industrial automation systems where fine‑tuned control actions are needed:

Controlling control valves in chemical, refining, and power generation plants
Regulating pump speed via analog drive interfaces
Supervisory analog command for continuous process loops
Modulating actuators in water and wastewater treatment systems
Scalable analog control architectures with distributed I/O

Advantages

High‑Resolution Output: Delivers fine control over field devices with 16‑bit precision.
Flexible Signal Support: Supports both current (4–20 mA) and configurable voltage outputs.
Strong Load Driving: Capable of driving loads up to 800 Ω per channel, enhancing device compatibility.
Fast Update Rates: Quick channel response supports responsive control loops.
Noise‑Resilient Design: Channel isolation reduces electrical interference for stable outputs.
Rack Integration: Seamless connection with standard Ovation backplane interfaces simplifies deployment.

Technical FAQs

1. How many analog outputs does this module provide?
It offers 8 independent analog output channels.

2. What signal formats are supported?
Standard 4–20 mA current loops and configurable voltage outputs.

3. What resolution does the module use?
Up to 16‑bit resolution for high‑precision control.

4. What is the output accuracy?
Approximately ±0.1 % of full scale.

5. What load resistance can it drive?
Up to 800 Ω per channel.

6. What is the update rate?
Typically between 5 ms and 10 ms per channel.

7. Is the module powered externally?
No; power is supplied via the Ovation rack backplane.

8. What industrial environments is it designed for?
Ambient conditions up to 55 °C and 95 % non‑condensing humidity.

9. How is field wiring handled?
Field connections are typically made via front‑accessible screw terminals.

10. Can it interface with other automation systems?
Yes, when integrated through the Ovation I/O network and system logic.
