Ovation 5X00301G01 Analog Output Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Ovation 5X00301G01 Analog Output Module

Name: Ovation 5X00301G01 Analog Output Module
Brand: Ovation DCS
SKU: 6438
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Ovation DCS
Item No.:5X00301G01
Product Origin:USA
Product Dimensions:125 × 35 × 160 mm
Product Weight:0.3kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Precision Analog Control for Process Automation

The Ovation 5X00301G01 Analog Output Module is a high‑performance field interface designed for use in Emerson Ovation Distributed Control Systems (DCS). This module delivers accurate and stable analog output signals to control field actuators, valve positioners, and continuous process devices.

Engineered for industrial environments, the 5X00301G01 integrates seamlessly into Ovation racks, offering reliable signal conversion, noise‑resilient output performance, and easy maintenance. Its robust design supports long‑term operational stability in demanding automation settings.

Technical Specifications

Parameter	Specification
Manufacturer	Emerson Ovation
Model	5X00301G01
Module Type	Analog Output Module
Output Channels	8 analog outputs
Output Signal	4 – 20 mA current loop
Load Driving Capability	Up to 500 Ω per channel
Resolution	12‑ to 16‑bit (system‑dependent)
Output Accuracy	±0.1 % of range typical
Update Rate	10 ms per channel
Isolation	Optical/transformer isolation per channel group
Backplane Interface	Standard Ovation rack connector
Power Source	Rack backplane power
Operating Temperature	0 °C to 55 °C
Storage Temperature	–40 °C to 70 °C
Humidity	5 % to 95 % non‑condensing
Dimensions (HxWxD)	Approx. 125 × 35 × 160 mm
Weight	Approx. 0.30 kg
Mounting	Rack slot installation

Applications

The 5X00301G01 Analog Output Module is widely used in process and industrial automation where precise control signals are required:

Controlling control valves in chemical and refining plants
Managing pump speed via variable frequency drives (VFDs)
Sending process‑scaled signals to actuators in power generation
Supervisory control of continuous process loops
Modulating field instruments requiring 4‑20 mA control signals

Advantages

High‑Precision Output: Accurate 4‑20 mA signals support fine control of field devices.
Multiple Channels: Eight independent outputs offer flexibility for complex systems.
Strong Load Driving: Supports substantial load impedance, enabling use with a variety of devices.
Noise‑Resilient Design: Isolation and robust output circuitry enhance signal integrity in industrial environments.
Seamless Backplane Integration: Standard rack interface ensures reliable communication and straightforward installation.

Technical FAQs

1. How many analog outputs are provided?
Eight independent 4‑20 mA outputs.

2. What signal type does it use?
Current loop (4‑20 mA) analog output.

3. What load resistance can it drive?
Up to approximately 500 Ω per channel.

4. What level of output accuracy does it offer?
Approximately ±0.1 % of range typical.

5. What is the update rate per channel?
Around 10 ms per channel.

6. Does it provide channel isolation?
Yes; isolation between channel groups enhances noise immunity.

7. Is an external power supply needed?
No; the module is powered from the rack backplane.

8. What environments is it designed for?
Typical industrial ambient conditions up to 55 °C and non‑condensing humidity.

9. How is field wiring connected?
Field wiring is typically terminated via front‑accessible screw terminals.

10. Can it interface with other DCS/PLC systems?
Yes, through integration with the Ovation I/O and control network.
