Product Overview
The Bently Nevada 330101-00-55-20-12-05 3300 XL 8 mm Proximity Probe is a precision eddy-current proximity probe designed for the 3300 XL 8 mm Proximity Transducer System. It provides accurate, non-contact measurement of shaft vibration and shaft position for continuous monitoring of critical rotating machinery.
This configuration includes a 5.5 in. (139.7 mm) probe case length, a 2.0 m (6.6 ft) FluidLoc® integrated cable, a Miniature ClickLoc™ coaxial connector, and CSA, ATEX, and IECEx hazardous-area approvals (Option 05). The FluidLoc® cable is engineered to help prevent fluid migration through the cable, improving long-term reliability in harsh industrial environments.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Bently Nevada |
| Model Number | 330101-00-55-20-12-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Series | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Measurement Principle | Non-contact Eddy Current |
| Unthreaded Length | 0.0 in. |
| Overall Case Length | 5.5 in. (139.7 mm) |
| Integrated Cable Length | 2.0 m (6.6 ft) |
| Cable Type | FluidLoc® Cable |
| Connector Type | Miniature ClickLoc™ Coaxial Connector |
| Mounting Thread | 3/8-24 UNF |
| Linear Measurement Range | 2.0 mm (80 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) ±5% |
| Frequency Response | 0 Hz to 10 kHz |
| Operating Temperature | -52°C to +177°C (-62°F to +351°F) |
| Minimum Target Diameter | 15.2 mm (0.6 in.) |
| Agency Approvals | CSA, ATEX, IECEx (Option 05) |
| Approximate Net Weight | 0.323 kg |
| Approximate Shipping Weight | 2.0 kg |
| Country of Origin | USA |
Typical Applications
The 330101-00-55-20-12-05 is designed for continuous machinery protection and condition monitoring in demanding industrial applications, including:
-
Steam turbines
-
Gas turbines
-
Centrifugal compressors
-
Industrial pumps
-
Electric motors
-
Generators
-
Gearboxes
-
Fans
-
Blowers
-
Turbo-expanders
Its 2.0-meter FluidLoc® cable provides installation flexibility while offering enhanced protection against moisture and fluid ingress, making it suitable for challenging operating environments.
Technical FAQs
1. What does this probe measure?
It measures shaft vibration and shaft position using non-contact eddy-current sensing technology.
2. What is the probe diameter?
The probe has an 8 mm sensing tip.
3. What is the overall probe case length?
This model features a 5.5 in. (139.7 mm) case length.
4. How long is the integrated cable?
It includes a 2.0 m (6.6 ft) integrated FluidLoc® cable.
5. What does cable option "12" indicate?
Option 12 specifies a FluidLoc® cable with a Miniature ClickLoc™ coaxial connector, designed to help minimize fluid migration within the cable assembly.
6. What approvals are included?
Option 05 includes CSA, ATEX, and IECEx hazardous-area certifications.
7. What mounting thread does the probe use?
The probe body uses a 3/8-24 UNF mounting thread.
8. What is the operating temperature range?
The probe operates from -52°C to +177°C (-62°F to +351°F).
9. Which system components are compatible with this probe?
It is designed for use with compatible 3300 XL Extension Cables and 3300 XL Proximitor Sensors configured for the appropriate system length.
10. Is this probe suitable for continuous online monitoring?
Yes. It is specifically designed for permanent installation in machinery protection and condition monitoring systems that comply with API 670 requirements.
