Bently Nevada 330101-00-50-10-01-00 3300 XL 8 mm Proximity Probe

Name: Bently Nevada 330101-00-50-10-01-00 3300 XL 8 mm Proximity Probe
Brand: Bently Nevada PLC
SKU: 9571
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Bently Nevada PLC
Item No.:330101-00-50-10-01-00
Product Origin:USA
Product Dimensions:Ø8 mm × 127.0 mm
Product Weight:0.2kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Product Overview

The Bently Nevada 330101-00-50-10-01-00 3300 XL 8 mm Proximity Probe is a precision non-contact eddy-current probe designed for use with the 3300 XL 8 mm Proximity Transducer System. It provides accurate measurement of shaft vibration and shaft position for continuous condition monitoring of rotating machinery in industrial applications.

This configuration features a 5.0 in. (127.0 mm) overall case length, a 1.0 m (3.3 ft) integrated standard cable, a Miniature ClickLoc™ coaxial connector with connector protector (Option 01), and Option 00 (no agency approvals). It is designed to operate with compatible 3300 XL Extension Cables and 3300 XL Proximitor Sensors as part of a complete transducer system.

Technical Specifications

Specification	Details
Manufacturer	Bently Nevada
Model Number	330101-00-50-10-01-00
Product Type	3300 XL 8 mm Proximity Probe
Series	3300 XL 8 mm Proximity Transducer System
Probe Diameter	8 mm
Measurement Principle	Eddy Current, Non-contact
Unthreaded Length	0.0 in.
Overall Case Length	5.0 in. (127.0 mm)
Integrated Cable Length	1.0 m (3.3 ft)
Cable Type	Standard Cable
Connector Type	Miniature ClickLoc™ Coaxial Connector with Connector Protector
Mounting Thread	3/8-24 UNF
Linear Measurement Range	2.0 mm (80 mils)
Scale Factor	7.87 V/mm (200 mV/mil) ±5%
Frequency Response	0 Hz to 10 kHz
Operating Temperature	-52°C to +177°C (-62°F to +351°F)
Minimum Target Diameter	15.2 mm (0.6 in.)
Agency Approval	None (Option 00)
Approximate Dimensions	Ø8 mm × 127.0 mm
Approximate Net Weight	0.18 kg
Approximate Shipping Weight	0.43 kg
Country of Origin	USA

Typical Applications

The 330101-00-50-10-01-00 is designed for continuous shaft displacement and vibration monitoring on a wide range of rotating equipment.

Typical applications include:

Steam turbines
Gas turbines
Centrifugal compressors
Industrial pumps
Electric motors
Generators
Gearboxes
Fans
Blowers
Turbo-expanders

Its 1.0-meter integrated cable and connector protector provide reliable installation in environments where additional connector protection is beneficial.

Product Features

Genuine Bently Nevada 3300 XL Series proximity probe.
High-precision 8 mm eddy-current sensing technology.
5.0-inch probe case for flexible installation.
Factory-installed 1.0 m standard cable.
Miniature ClickLoc™ connector with connector protector.
Excellent linearity and repeatable measurement accuracy.
Rugged stainless steel construction.
Compatible with 3300 XL Extension Cables and Proximitor Sensors.
Stable long-term measurement performance.
Designed for continuous machinery condition monitoring.

Technical FAQs

1. What is the primary function of this probe?
It measures shaft vibration and shaft position without physical contact using eddy-current sensing technology.

2. What is the probe diameter?
The sensing tip diameter is 8 mm.

3. What is the overall case length?
The probe case length is 5.0 inches (127.0 mm).

4. What cable length is included?
This configuration includes a 1.0 m (3.3 ft) integrated standard cable.

5. What does connector option "01" indicate?
Option 01 specifies a Miniature ClickLoc™ coaxial connector with connector protector, providing additional mechanical protection for the connector assembly.

6. Does this model include hazardous-area certifications?
No. Option 00 indicates that no CSA, ATEX, or IECEx approvals are included.

7. What mounting thread is used?
The probe body uses a 3/8-24 UNF mounting thread.

8. What is the operating temperature range?
The probe operates from -52°C to +177°C (-62°F to +351°F).

9. Which accessories are compatible with this probe?
It is intended for use with compatible 3300 XL Extension Cables and 3300 XL Proximitor Sensors.

10. Is this probe suitable for continuous online monitoring?
Yes. It is engineered for permanent installation on critical rotating machinery requiring continuous condition monitoring.
